Chapter 3: System Setup
3. Wire the power adapter cabling into the cable opening on the bracket,
then place the adapter inside the bracket.
Cable opening
Power adapter cable
79
Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved.
APPC 1230T/1231T/1235T/1530T/1531T/1730T/1731T/1930T/1931T User Manual
