Chapter 2: Jumpers and Connectors

COM3 RI Pin Power Select

(APPC 1231T/APPC 1531T/APPC 1731T/APPC 1931T only)
Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: JP9
1 3
Pin
1-2 On
2-3 On
1-2 On: default
Pin
1
2
3
Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved.
Settings
RING
+5V
Definition
SP3_RI
SP3_PSRI
VCC5

COM4 RI Pin Power Select

(APPC 1231T/APPC 1531T/APPC 1731T/APPC 1931T only)
Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: JP10
1 3
Pin
1-2 On
2-3 On
1-2 On: default
Pin
1
2
3
30
APPC 1230T/1231T/1235T/1530T/1531T/1730T/1731T/1930T/1931T User Manual
Settings
RING
+12V
Definition
SP4_RI
SP4_PSRI
12V
