Chapter 3: System Setup
6. Place the SATA drive in the chassis and then use the provided mounting
screws to secure the drive in the chassis.
Connect the SATA data cable and SATA power cable to the
connectorson the SATA drive.
Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved.
SATA drive
SATA data cable
SATA power cable
55
APPC 1230T/1231T/1235T/1530T/1531T/1730T/1731T/1930T/1931T User Manual
