Chapter 4: BIOS Setup

CPU Configuration

This section is used to configure the CPU.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
CPU Configuration
Intel(R) Atom (TM) CPU
Processor Type
Supported
EMT64
2132 MHZ
Proceddor Speed
533MHZ
System Bus Speed
16
Ratio Status
16
Actual Ratio
533MHZ
System Bus Speed
30661
Processor Stepping
262
Microcode Revision
2x56 k
L1 Cache RAM
2x512 k
L2 Cache RAM
Dual
Processor Core
Supported
Hyper-Threading
[Enabled]
Hyper-Threading
Execute Disable Bit [Enabled]
Limit CPUID Maximum
[Disabled]
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Hyper-Threading
This field is used to enable or disable hyper-threading.
Execute Disable Bit
This field is used to enable or disable execute disable bit. When this field is
set to Disabled, it will force the XD feature flag to always return to 0. XD can
prevent certain classes of malicious buffer overflow attacks when combined
with a supporting OS (Windows Server 2003 SP1, Windows XP SP2, SuSE
Linux 9.2, RedHat Enterprise 3 Update 3).
Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved.
Limit CPUID Maximum
The CPUID instruction of some newer CPUs will return a value greater
than 3. The default is Disabled because this problem does not exist in the
Windows series operating systems. If you are using an operating system
other than Windows, this problem may occur. To avoid this problem, enable
this field to limit the return value to 3 or lesser than 3.
Enabled for Windows XP and
Linux (OS optimized for Hyper-
Threading Technology) and
Disabled for other OS (OS not
optimized for Hyper-Threading
Technology).
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
91
