Chapter 3: System Setup

Placing Panel Mount Hole Blocks

1. Locate the panel mount openings on the chassis.
The APPC series comes with panel mount hole blocks to cover the panel
mount openings on the chassis to prevent dust invasion. You can also
choose to cover the panel mount holes when VESA mount is used.
Panel Mount Hole Block
(APPC 1930T/APPC1 931T)
Panel Mount Hole Block
(APPC 1730T/APPC 1731T/APPC 1530T/APPC 1531T/
APPC 1230T/APPC 1231T/APPC 1235T)
76
