Chapter 1: Product Introduction

Knowing Your APPC Series

Rear Top

Antenna holes
Panel mounting hole CFast
Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved.
Backlight on/off Decrease Brightness
Increase Brightness
Power switch
Panel mounting hole
Antenna holes for optional 3.5G/ WiFi/ Bluetooth
The 3 external antenna holes are used to mount and connect optional 3.5G/
WiFi/ Bluetooth antennas.
CFast Card Socket
Used to insert a CFast card.
Power Switch
Press to power-on or power-off the panel PC.
Panel Backlight Control Buttons
(APPC1231T/ APPC1531T APPC1731T/ APPC1931T only)
Backlight On/Off
Press to turn-on or turn-off the display
Increase Brightness
Press to increase brightness of the screen.
Decrease Brightness
Press to decrease brightness of the screen.
8 brightness level available:
30%, 40%, 50%, 60%, 70%, 80%, 90% and 100%
13
APPC 1230T/1231T/1235T/1530T/1531T/1730T/1731T/1930T/1931T User Manual
