Chapter 4: BIOS Setup
Onboard Serial Port Max Baud Rate
This field configures the maximum baud rate of the serial port 3, the options
are 115200 bps and 921600 bps.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Chipset Boot
Serial Port 3 Configuration
[Enabled]
Serial Port
Device Settings IO=2E8H; IRQ=6;
[IO=2E8H; IRQ=6;]
Change Settings
Onboard Serial Port Max Baud Rate [115200
Onboard Serial Port Max Baud Rate
115200 bps
921600 bps
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved.
Security Save & Exit
Change the Serial Port Max Baud
Rate. Select <115200 bps> or
<921600 bps>
bps]
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
H/W Monitor
This section is used to configure the hardware temperature, fan speed and
voltages.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Chipset
Pc Health Status
CPU Temperature
System Temperature
CPU:Vcore
+3.3V
+5V
+12V
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
98
APPC 1230T/1231T/1235T/1530T/1531T/1730T/1731T/1930T/1931T User Manual
Save & Exit
Boot Security
: +39 C
: +39 C
: +1.168 V
: +3.328 V
: +5.017 V
: +11.827 V
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
