Chapter 3: System Setup
7. Install the drive bay back to its original position.
Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved.
8. Attach one end of the RF cable onto the module.
9. Mount the other end of the cable to the Bluetooth mounting hole
located at the rear top panel of the chassis.
75
APPC 1230T/1231T/1235T/1530T/1531T/1730T/1731T/1930T/1931T User Manual
Attach RF
cable to the module
