Appendix D: Power Consumption

Appendix D: Power Consumption
Power Consumption Management
Purpose
The purpose of the power consumption test is to verify the power dissipation
of the system and the load of the power supply.
Test Equipment
1. PROVA CM-07 AC/DC CLAMP METER
2. Burn-in test ver:2.0
Device Under Test
DUT: sys#1/
Test Procedure
1. Power up DUT and then boot Windows 7.
2. Enter the standby mode (HDD power down).
3. Measure the power consumption and record it.
4. Run the Burn-in test program to apply 100% full loading.
5. Measure the power consumption and record it.
Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved.
APPC 1930T/1931T
Full-Loading Mode
Total
Standby Mode
Total
APPC 1730T/1731T
Full-Loading Mode
Total
Standby Mode
Total
112
APPC 1230T/1231T/1235T/1530T/1531T/1730T/1731T/1930T/1931T User Manual
+12V +24V
3.2A 1.65A
38.4W 39.6W 37.8W
0.75A 0.41A
9W 9.84W 10.8W
+12V +24V
4.2A 2A
50.4W 48W 48.9W
0.74A 0.41A
8.88W 9.84W 10.2W
+30V
1.26A
0.36A
+30V
1.63A
0.34A
