Chapter 2: Jumpers and Connectors
LCD Panel VDD Power Select
Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: JP5
1
3
Pin
Settings
1-2 On
3.3V
2-3 On
5V
1-2 On: default
Pin
1
2
3
Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved.
Model
APPC1230T
APPC1231T
APPC1235T
APPC1530T
APPC1531T
APPC1730T
APPC1731T
APPC1930T
APPC1931T
Definition
VCC3
Power for VDD
VCC5
Touch 4/5 Wire Select
Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: JP7
1
3
Pin
1-2 On
2-3 On
1-2 On: default
28
APPC 1230T/1231T/1235T/1530T/1531T/1730T/1731T/1930T/1931T User Manual
Settings
5 wire
4 wire
