Chapter 3: System Setup
5. Connect one end of the provided cable to the connector on the
module.
Connector on
the module
Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved.
Cable
6. Install the module to the SATA port via the connector at the solder side
of the module and then secure the module using the mounting screw
you removed in step 2.
63
APPC 1230T/1231T/1235T/1530T/1531T/1730T/1731T/1930T/1931T User Manual
SATA DOM
Mounting
screw
