Chapter 3: System Setup
4. Place the SATA hard drive on the drive bay.
Drive bay
Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved.
5. Align the mounting holes that are on the sides of the SATA drive
SATA drive
54
with the mounting holes on the drive bay and then use the provided
mounting screws to secure the drive in place.
APPC 1230T/1231T/1235T/1530T/1531T/1730T/1731T/1930T/1931T User Manual
Mounting
screw
