Chapter 3: System Setup
3. Remove the mounting screws of the drive bay.
Mounting
screw
Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved.
4. Remove the drive bay and locate the Bluetooth connector and
mounting hole on the mainboard.
73
APPC 1230T/1231T/1235T/1530T/1531T/1730T/1731T/1930T/1931T User Manual
Bluetooth
connector
Mounting
hole
