Chapter 4: BIOS Setup

Boot

This section is used to configure the boot features.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Chipset
Boot
Boot Configuration
1
Setup Prompt Timeout
Bootup NumLock State [On]
Quiet Boot [Disabled]
CSM16 Module Version 07.65
GateA20 Active [Upon Request]
Option ROM Messages [Force BIOS]
[Disabled]
Interrupt 19 Capture
Boot Option Priorities
Boot Option #1 [SATA SM: 4GB SATA...]
Hard Drive BBS Priorities
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Setup Prompt Timeout
This section configures the number of seconds to wait for the setup
activation key.
Bootup NumLock State
This allows you to determine the default state of the numeric keypad. By
default, the system boots up with NumLock on wherein the function of the
numeric keypad is the number keys. When set to Off, the function of the
numeric keypad is the arrow keys.
Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved.
Security Save & Exit
Number of seconds to wait
for setup activation key.
65535(0xFFFF) means indefinite
waiting.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Quiet Boot
Enabled Displays OEM logo instead of the POST messages.
Disabled Displays normal POST messages.
GateA20 Active
Upon Request GA20 can be disabled using BIOS services.
Always Do not allow disabling GA20; this option is useful when
any RT code is executed above 1MB.
Option ROM Messages
This field is used to set display mode for Option ROM.
Interrupt 19 Capture
Allows Option ROMs to trap Interrupt 19 when enabled.
Boot Option Priorities
Adjust the boot sequence of the system. Boot Option #1 is the first boot
device that the system will boot from, next will be #2 and so forth.
102
