Chapter 2: Jumpers and Connectors
COM1 RI Pin Power Select
(APPC 1230T/APPC 1235T/APPC 1530T/APPC 1730T/APPC 1930T only)
Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: JP12
1
3
Pin
1-2 On
2-3 On
1-2 On: default
Pin
1
2
3
Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved.
Settings
RING
+5V
Definition
SP1_RI
SP1_PSRI
VCC5
COM2 RI Pin Power Select
(APPC 1230T/APPC 1235T/APPC 1530T/APPC 1730T/APPC 1930T only)
Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: JP13
1
3
Pin
1-2 On
2-3 On
1-2 On: default
Pin
1
2
3
29
APPC 1230T/1231T/1235T/1530T/1531T/1730T/1731T/1930T/1931T User Manual
Settings
RING
+12V
Definition
SP2_RI
SP2_PSRI
+12V
