Chapter 2: Jumpers and Connectors
Touch 4/5 Wire Select
Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: JP4
1
3
Pin
Settings
1-2 On
5 wire
2-3 On
4 wire
1-2 On: default
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.
COM1 RI Pin Power Select
Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: JP12
1
3
Pin
Settings
1-2 On
RING
2-3 On
+5V
1-2 On: default
Pin
Definition
1
SP1_RI
2
SP1_PSRI
3
VCC5
17
OPPC 1540HT-J1900/1940HT-J1900 User Manual
