Chapter 2: Jumpers and Connectors

Dimming Signal Level Select

Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: JP6
1 3
Pin Settings
1-2 On 3.3V
2-3 On 5V
1-2 On: default
Pin Definition
1 VCC3
2 Power for Dimming
3 VCC5
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
Model
APPC 1240T
APPC 1940T
APPC 1540T
APPC 1740T

LCD Panel VDD Power Select

Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: JP3
1 3
Pin Settings
1-2 On 3.3V
2-3 On 5V
1-2 On: default
Pin Definition
1 VCC3
2 Power for VDD
3 VCC5
13
Model
APPC 1240T
APPC 1540T
APPC 1740T
APPC 1940T
