Clear Programmed Data / User Settings - Muratec MFX-1330 Field Engineering Manual

Memory Switch 72 - Operation
Initial
Switch
Setting
7 0 Factory use only
6 0 Factory use only
5 0 Factory use only
4 0 Factory use only
3 0 Factory use only
2 0 Factory use only
1 1 Erase polled document
0: No
1: Yes
0 1 Print TCR after the batch
transmission
0: No
1: Yes
Memory Switch 73 ∼ 99 --- Factory use only

3.4 Clear Programmed Data / User Settings

User programmed information such as autodialer entries, date, time, Transmit Terminal Identifier (TTI),
Subscriber ID, etc., are stored in the unit's Random Access Memory (RAM). A battery back up holes this
information, when the power is lost.
This function does not clear the machine parameters, memory switches and unique switches. Therefore, this
setting is useful to reset the user-programmed information but leave specific parameters and switches
configured for a particular telephone system, etc.
To reset only each switch, see page 3-3, 3-48 and 3-74.
Note: If desired, the All RAM Clear setting can be used to erase all users programmed information, all
documents in memory, and reset the memory switches and machine parameters to factory defaults.
For information on the All RAM Clear setting, see the next page.
1. To clear programmed data and user settings, from standby, press MENU, *, 0, 2.
Clear User Settings
Yes → Enter
2. Press ENTER.
Note: To finish the operation without performing initialization, press CANCEL.
Adjust
Determines if a document stored for polling is
erased after being polled.
Determines if printing the confirmation report after
completing the batch transmission.
3-68
Usage/Comments
