Muratec MFX-1330 Field Engineering Manual page 35

Machine Parameter 015
Initial
Switch
Setting
7 1 FBS scanner registration
adjustment (Horizontal)
6 0
5 0
Adjusts the start point to
4 0
scan the document.
3 0
The plus setting increases
2 0
the left margin and the minus
1 1
setting decreases it.
0 0
1 step = 2 / 600 dpi
Note: These values
are factory set and should
not be adjusted unless
instructed by a Muratec
technical representative.
Machine Parameter 016
Initial
Switch
Setting
7 0 Adjustment of the scanning
stretching and squeezing for
6 0
FBS.
5 0
(Horizontal)
4 0
3 0
The plus setting stretches the
2 0
image data and the minus
1 0
setting squeezes it.
0 0
Each setting changes by
0.1%
Adjust
Switch
127 steps 01111111
(0.0847 mm)
-127steps
Adjust
3-7
Usage/Comments
76543210 Settings
+10.76 mm
:
00100000 +2.71 mm
:
00010000 +1.36 mm
:
00001000 +0.68mm
:
00000000
:
10000010 -0.17 mm
:
10001000 -0.68 mm
:
10010000 -1.36 mm
:
10100000 -2.71 mm
:
11111111 -10.76 mm
Usage/Comments
Switch 76543210 Settings
00001111 +1.5 %
:
00001000 +0.8 %
:
00000100 +0.4 %
:
00000010 +0.2 %
00000001 +0.1 %
00000000 0 %
10000001 -0.1 %
10000010 -0.2 %
:
10000100 -0.4 %
:
10001000 -0.8 %
:
10001111 -1.5 %
