If a printout jams inside your machine

1. If paper jams occur the LCD will show:
Open 1st Side Cover
Please remove Paper
Follow these procedures to clear the paper jam.
If a paper jam occurs during fax reception, the machine will store the received document in the
memory and printout them automatically when you have cleared the paper jam.
CAUTION: When you open the side cover to remove the paper, DO NOT touch the fuser roller.
Important: Do not touch the drum cartridge surface. Scratches or smudges will result in poor print
quality.
Removing jammed paper
To clear a printout jammed inside your machine:
1. Pull the release lever to open the side cover.
If the optional second cassette is attached, also open the 2nd side cover.
2. Carefully remove the jammed paper in the direction shown.
Note: Avoid getting unfixed toner on your hands and clothes when removing jammed paper.
Jammed in feed area
4-8
