Maintenance Schedule - Muratec MFX-1330 Field Engineering Manual

5.1 Maintenance schedule

Scanning Section
Parts Name
Roller Separator*1
Pad Separator*1
Contact glass & Pane*2
Sheet document press
(White sheet) *2
Exposure Lamp*2
Roller Feed
Roller Exit
*1 Replace the parts at the same time.
*2 It is not a maintenance parts. However, please replace when it becomes not works.
Printer Section
Parts Name
Roller Transfer
Roller Register
Roller Pickup MP
Printer Fuser
Roller Exit
Developing Section
Parts Name
Drum cartridge
MFX-1330 Toner cartridge
F-300 Toner cartridge
Drum charge wire and LED print
head
Note: " " means to clean the mechanism when a paper take-up or transport failure or print quality problems occurs.
Maintenance Cycle (pages)
Clean Replace
60,000 or
2 years
60,000 or
2 years
Clean when
—
dirty
Clean when
—
dirty
— 10,000 hours
100,000
100,000
Maintenance Cycle (pages)
Clean Replace
— 60,000
10,0000
60,000 or
2 years
— 100,000
10,0000
Maintenance Cycle (pages)
Clean Replace
— 20,000
— 5,000
— 7,500
—
5-2 5-2
QTY Reference Page
1 5-24
1 5-36
1 —
1 5-85
1 5-19
1 5-25
1 5-27
QTY Reference Page
1 5-47
1 5-48
1 5-51
1 5-52
1 5-56
QTY Reference Page
1
1
See Operating
1
Instructions
1
