Muratec MFX-1330 Field Engineering Manual page 38

Machine Parameter 025
Initial
Switch
Setting
7 0 Background level adjustment
starting position
6 0
5 0
Adjusts the number of the
4 0
steps from the home sensor
3 0
of the mirror carriage OFF
2 0
to the background level
1 0
adjusting start position.
0 0
1 step = 0.0212 mm
Machine Parameter 026 ∼ 029 --- Factory use only
Adjust
Switch 76543210
127steps 01111111
64 steps 01000000
:
32 steps 00100000
16 steps 00010000
8 steps
-8 steps
-16 steps 10010000
-32 steps 10100000
-64 steps 11000000
-127steps
3-10
Usage/Comments
Settings
+2.70 mm
:
+1.36 mm
+0.68 mm
:
+0.34 mm
:
00001000 +0.17 mm
:
00000000 15.35 mm
:
10001000 -0.17 mm
:
-0.34 mm
:
-0.68mm
:
-1.36 mm
:
11111111 -2.70mm
Initial setting
