Muratec MFX-1330 Field Engineering Manual page 47

Machine Parameter 180
Initial
Switch
Setting
7 0 Printer registration
adjustment (Vertical) at the
6 0
1st cassette for printing.
5 0
4 0
Adjusts the start point to
3 0
print.
2 0
1 0
The plus setting increases
0 0
the top margin and the minus
setting decreases it.
Each setting changes by
0.1 mm.
Machine Parameter 181
Initial
Switch
Setting
7 0 Printer registration
adjustment (Vertical) at the
6 0
2nd cassette for printing.
5 0
4 0
Adjusts the start point to
3 0
print.
2 0
1 0
The plus setting increases
0 0
the top margin and the minus
setting decreases it.
Each setting changes by
0.1 mm.
Adjust
Switch
127 steps
32 steps
16 steps
8 steps
Note: Set this switch after setting the margin to
"0 mm" in Unique Switch 52. Then, after setting
this switch, set the margin to the initial setting (4
mm) in Unique Switch 52.
Adjust
Switch
127 steps
32 steps
16 steps
8 steps
Note: Set this switch after setting the margin to
"0 mm" in Unique Switch 52. Then, after setting
this switch, set the margin to the initial setting (4
mm) in Unique Switch 52.
3-19
Usage/Comments
76543210 Settings
01111111 +12.7 mm
:
00100000 +3.2 mm
:
00010000 +1.6 mm
:
00001000 +0.8 mm
:
00000000 0 mm Initial setting
Usage/Comments
76543210 Settings
01111111 +12.7 mm
:
00100000 +3.2 mm
:
00010000 +1.6 mm
:
00001000 +0.8 mm
:
00000000 0 mm Initial setting
