3.11 Print Machine Parameters, Memory Switch and
Unique Switch Settings
This function instructs the unit to print a list of the machine parameter, memory switch and unique switch
settings. The list shows the default and current settings for each. After printing, the unit returns to standby.
1. Press MENU, *, 1, 0.
Memory Switch
** Printing **

3.12 Factory Functions

This factory functions provide several machine testes including LED and LCD tests, a keypad test, memory
tests, a RTC test, and optional RS-232C test port test.
1. Press MENU, *, 1, 1.
Factory Function List
2. To select the desired test mode, press number as indicated in the following list.
• Prints a list of the Factory Functions

• LED test

• LCD test
• Key Panel test
• SRAM check
• DRAM check
• RTC test
• Page memory check
• Generate bell test

3.12.1 Function List

Press MENU, *, 1, 1. Then press ENTER. A list of the Factory Functions will be printed. After printing the unit
will return to standby.
3.12.2 LED Test
1. Press MENU, *, 1, 1,
LED Test
Pressing START once, all green LEDs will turn on.
Pressing START twice, all red LEDs will turn on.
Pressing START three times, all LEDs will turn on.
2. Press STOP to exit the test mode.
/ /Enter
, then press ENTER.
3-102
