Muratec MFX-1330 Field Engineering Manual page 258

Hide thumbs Also See for MFX-1330:
Table of Contents

Advertisement

9) Release the locking tab, and then remove the Bracket toner sensor A.
10) Remove the TS1 mounting screw, and then remove the TS1.
Bracket toner sensor A
TS1
5-68
5-68
Bracket toner sensor A
