Muratec
MFX-1200
FACSIMILE SYSTEM
FIELD ENGINEERING MANUAL
US version 1.0
(August 30, 2000)
MURATA MACHINERY, LTD
COMMUNICATION EQUIPMENT DIV.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MFX-1600 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Muratec MFX-1600

Summary of Contents for Muratec MFX-1600

  • Page 1 Muratec MFX-1200 FACSIMILE SYSTEM FIELD ENGINEERING MANUAL US version 1.0 (August 30, 2000) MURATA MACHINERY, LTD COMMUNICATION EQUIPMENT DIV.

  • Page 2: Led Safety Label

    Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions. Important: Muratec does not recommend the independent replacement of this battery. The battery is sold only as a component part of the main control PCB and Battery PCB, and cannot be purchased separately from Muratec.
  • Page 3 Sweden only VARNING Explosionsfara vid felaktigt batteribyte. Använd samma batterityp eller en ekvivalent typ som rekommenderas av apparattillverkaren. Kassera använt batteri enligt fabrikantens instruktion. Finland only VAROlTUS Paristo voi räjähtää, los se on virheellisesti asennettu. Vaihda paristo ainoastaan laitevalmistajan suosittelemaan tyyppiin. Hävitä...

  • Page 4: Table Of Contents

    1.1 Product Description ..........................1-1 1.2 Specifications............................1-2 Section2 Machine Composition ..........2-1 2.1 MFX-1200 Interconnect Block Diagram (1/2) ..................2-1 MFX-1600 Interconnect Block Diagram (1/2) .....................2-3 2.2 Main Control PCB ..........................2-5 2.3 Network Control Unit (NCU) PCB ......................2-6 2.4 Power Supply Unit (PSU) ........................2-7 2.5 Sensors..............................2-8...
  • Page 5 Machine Parameter B:8........................3-11 Machine Parameter D:0........................3-12 Machine Parameter D:1........................3-12 Machine Parameter D:2........................3-12 Machine Parameter D:3........................3-12 Machine Parameter D:4........................3-13 Machine Parameter D:5........................3-13 Machine Parameter D:6........................3-13 Machine Parameter D:7........................3-13 Machine Parameter D:8........................3-14 Machine Parameter D:9........................3-14 Machine Parameter F:0 ........................3-14 Machine Parameter F:1 ........................3-15 Machine Parameter F:2 ........................3-15 Machine Parameter F:3 ........................3-16 Machine Parameter F:4 ........................3-16...
  • Page 6 Unique Switch b:6 - Transmission......................3-43 Unique Switch b:7 — Transmission .....................3-43 Unique Switch b:8 - Transmission......................3-44 Unique Switch c:0 - Reception ......................3-44 Unique Switch c:1 - Reception ......................3-45 Unique Switch c:2 - Reception ......................3-46 Unique Switch c:3 - Reception ......................3-46 Unique Switch d:0 - Modem .........................3-47 Unique Switch d:1 - Modem .........................3-47 Unique Switch d:2 - Modem .........................3-48...
  • Page 7 3.16.1 Set consumable order sheet .....................3-74 3.16.2 Print consumable order sheet ....................3-75 3.16.3 Clear consumable order sheet ....................3-75 3.17 DRAM Clear............................3-76 3.18 Clear Life Monitor ..........................3-76 3.19 Clear Optional Data ..........................3-76 3.20 Set Service Code..........................3-77 3.21 Life monitor maintenance .........................3-77 3.22 JP1, JP2 Battery Backup ........................3-78 3.23 Update the software..........................3-79 Section4 Troubleshooting Procedures........4-1...
  • Page 8 RS-232C interface cable ........................6-6 Signal direction ............................6-6 RS-232C Test............................6-6 6.3 Page Counter............................6-7 Packaging contents: ..........................6-7 Installation ..............................6-7 6.4 AL-200 (only for MFX-1600) .........................6-8 Packaging contents: ..........................6-8 Installation ..............................6-8 6.5 OP-100/NP-200 ..........................6-12 Packaging contents: ..........................6-12 Attaching the OP-100 (and NP-200) ....................6-13 Installing the Printer driver........................6-16...

  • Page 9: Section 1 General Description

    Section 1 General Description 1.1 Product Description The MFX-1200 and MFX-1600 is Multi-function product with flat bed scanner and Group 3 and V.34 HDX modem facsimile machine. Documents are printed on plain paper using dry electrophotographic printing.

  • Page 10: Specifications

    208 mm(Fax), 210 mm(Copy) Transmission speed Approx. 6 seconds Approx. 2 seconds Based on transmission of ITU-T Based on transmission of ITU-T Test Document 1 to a Muratec fax Test Document 1 to a Muratec fax machine. machine. Document Memory Standard:...
  • Page 11 When the Extension paper tray and Bypass tray are retracted. Weight Approx. 23.3 Kg (51.4 lbs) without consumables and trays. Optional products Optional telephone handset 2nd paper cassette Printer controller kit Network interface card Second phone line kit (only for MFX-1600) RS-232C interface kit Mechanical page counter...

  • Page 12: Section2 Machine Composition

    Section2 Machine Composition 2.1 MFX-1200 Interconnect Block Diagram (1/2)

  • Page 13: Mfx-1200 Interconnect Block Diagram (1/2)

    MFX-1200 Interconnect Block Diagram (2/2)

  • Page 14: Mfx-1600 Interconnect Block Diagram (1/2)

    MFX-1600 Interconnect Block Diagram (1/2)
  • Page 15 MFX-1600 Interconnect Block Diagram (2/2)

  • Page 16: Main Control Pcb

    2.2 Main Control PCB The main control PCB controls the operations of all machine functions. Jumper JP2 on the main control PCB is used for battery back-up of the SDRAM. Removing JP2 will initialize the SDRAM. If the power is turned off, the battery will provide up to 72 hours (8MB) of back-up when fully charged.

  • Page 17: Network Control Unit (Ncu) Pcb

    2.3 Network Control Unit (NCU) PCB The NCU PCB provides the connection to the telephone line. It consists of the interface circuit, dial pulse generator, ring signal detector and telephone control circuit. MODULAR NCU PCB GENERATOR TONE +24V, +5V, GND +12V, -12V NCU PCB block diagram Major components of the NCU...

  • Page 18: Power Supply Unit (Psu)

    2.4 Power Supply Unit (PSU) The power supply unit receives the input line voltage and currents it to output voltages of +5 VDC, +24 VDC, +12 VDC, and -12 VDC. The heater circuit controls output voltage to the fuser heater according to instructions received from the heater control circuit.

  • Page 19: Sensors

    2.5 Sensors 2.5.1 Sensor Locations The following illustration shows the relative positions of the machine’s sensors. TXIL COVER SW DRUM SW HOME HPES CASOP JCOP...

  • Page 20: Sensor Descriptions

    2.5.2 Sensor Descriptions The following table gives a brief description of each sensor and its function. Code Name Detects Sensor Type Document sensor 1 Presence of document in feeder Photo interrupter Document sensor 2 Leading and trailing edge of document Mechanical Switch HOME Mirror carriage home...

  • Page 21: Document Scanning Sequence

    2.6 Document Scanning Sequence 2.6.1 Document Detection When a document is placed into the document feeder, Document Sensor 1 (DS1) is activated and you will hear the short beep. 2.6.2 Document Separation Document separation is the process that allows a multi-page document to go through the scanner one page at a time.

  • Page 22: Document Discharge

    When DS2 detects the trailing edge of the document, the image signal output is turned off. The scanner continues to remain active for a few more seconds in case there is another document to follow. Separator roller Pick up roller Retard roller Feed roller A Press roller A...

  • Page 23: Recording Section

    2.7 Recording Section 2.7.1 Recording Paper Feed Path A sheet of the recording paper is separated from the remaining paper by the friction of the pickup roller. The paper is moved along the paper guide until it reaches the platen roller. Is then fed by the rotation of the platen roller.

  • Page 24: Drum Charge

    2.8.1 Drum Charge The Drum is charged with static electricity before LED exposure. The Rotating Charge Brush is used for the charging method. The rotating brush charging generate little ozone in the printer. Because the charge is directly given to the Drum, the Drum can be charged by low voltage.

  • Page 25: Image Transfer

    2.8.4 Image Transfer Image transfer is the process of transferring the toner image created on the Drum in the developing process to paper. We use the Roller Image Transfer instead of the Corona Image Transfer, as the image transfer method. In the Roller Image Transfer, there is little generation of ozone due to corona discharge. Also, there is no blur of toner because the paper is always pressed by the Drum and the Image Transfer Roller.

  • Page 26: Fusing

    2.8.6 Fusing An Overview The toner image transferred on to the paper is securely fixed. A heat roller system is used as the fusing system. The toner image is fused by Heater Roller heated by the Heater Lamp, and securely fixed by the pressure between the Heater roller and Press rollers. A Thermistor detects and controls the Heater Roller temperature.
  • Page 27 Fusing temperature 1) Warming Up After the initialization of the printer, warming up of the printer starts and the Heater Lamp turns ON until the temperature of the Heater Roller reaches approx. 185 °C. 2) Printing When the printer obtains the printing command from its controller, the Heater Roller is maintained at 185 °C.

  • Page 28: Section3 Adjustment Procedures

    Section3 Adjustment Procedures 3.1 Field Service Program Modes The fax machine feature maintenance modes for machine adjustment. Each mode is listed below along with the command used to activate the mode and a brief functional description. Note: When you press “ * ”, you will hear short beeps. However continue the operation, as it is no problem.

  • Page 30: Machine Parameter Adjustment

    3.2 Machine Parameter Adjustment 3.2.1 Setting the Machine Parameters These switches are used to program internal machine parameters. The primary back up battery maintains these settings if power is lost. 1. From standby, press Program key, *, 0. Set Parameters /Enter 2.

  • Page 31: Machine Parameter A:0

    Machine Parameter A:0 Initial Switch Adjust Usage/Comments Setting Country code The country code enables the ROM to output the correct programming information for the respective country. Machine Parameter A:1 Initial Switch Adjust Usage/Comments Setting Non-loaded cable compensation (TX) 0 db 4 db 8 db 12 db...

  • Page 32: Machine Parameter A:2

    Machine Parameter A:2 Initial Switch Adjust Usage/Comments Setting Factory use only Factory use only Factory use only Factory use only DTMF output level See table below. attenuation Machine Parameter A:2 … DTMF output level attenuation --- (Factory default is -1 dB) Switch 3 Switch 2 Switch 1...

  • Page 33: Machine Parameter A:4

    Note: These values are 00110101 45.05 mm factory set and should not be 00110110 45.90 mm adjusted unless instructed by 00110111 46.75 mm a Muratec technical 00111000 47.60 mm representative. 00111001 48.45 mm 11111111 216.75 mm Machine Parameter A:4 Initial...

  • Page 34: Machine Parameter B:1

    10.20 mm Initial setting Note: These values are 00001101 11.05 mm factory set and should not be 00001110 11.90 mm adjusted unless instructed by 00001111 12.75 mm a Muratec technical 00010000 13.60 mm representative. 00010001 14.45 mm 11111111 216.75 mm...

  • Page 35: Machine Parameter B:4

    56.10 mm Note: These values are 01000011 56.95 mm factory set and should not be 01000100 57.80 mm adjusted unless instructed by 01000101 58.65 mm a Muratec technical 01000111 59.50 mm representative. 11111111 216.75 mm Machine Parameter B:2 Initial Switch Adjust...

  • Page 36: Machine Parameter B:6

    Machine Parameter B:3 Initial Switch Adjust Usage/Comments Setting FBS scanner registration Switch 76543210 Settings adjustment (Horizontal) 00000111 3.5 mm Maximum Adjusts the start point to scan 00000110 3.0 mm the document. 00000101 2.5 mm The plus setting increase the 00000100 2.0 mm left margin and the minus 00000011...

  • Page 37: Machine Parameter B:8

    Machine Parameter B:5 Initial Switch Adjust Usage/Comments Setting FBS scanner registration adjustment (Horizontal) Switch 7654 Max. 0011 4.2 mm Adjusts the horizontal 0010 2.8 mm scanning range. 0001 1.4 mm The plus setting increase the 0000 Initial setting scanning range and the 1001 -1.4 mm minus setting decrease it.

  • Page 38: Machine Parameter D:1

    0.26 mm Note: These values 00000100 0.34 mm are factory set and should 00000101 0.43 not be adjusted unless 00000111 0.51 mm instructed by a Muratec technical representative. 01111111 10.80 mm Machine Parameter B:9 C:9 --- Factory use only 3-11...

  • Page 39: Machine Parameter D:4

    Machine Parameter D:0 Initial Switch Adjust Usage/Comments Setting Slice level adjustment of Switch 76543210 “Light” in the mode without 00000000 Darkest setting Grayscale. 00000001 00000010 Initial setting 00000011 00000100 Lightest setting Machine Parameter D:1 Initial Switch Adjust Usage/Comments Setting Slice level adjustment of Switch 76543210 “Lighter”...

  • Page 40: Machine Parameter D:8

    Machine Parameter D:4 Initial Switch Adjust Usage/Comments Setting Slice level adjustment of Switch 76543210 “Dark” in the mode without 00000000 Darkest setting Grayscale. 00000001 00000010 Initial setting 00000011 00000100 Lightest setting Machine Parameter D:5 Initial Switch Adjust Usage/Comments Setting Slice level adjustment of Switch 76543210 “Light”...

  • Page 41: Machine Parameter F:2

    Machine Parameter D:8 Initial Switch Adjust Usage/Comments Setting Slice level adjustment of Switch 76543210 “Darker” in Grayscale. 00000000 Darkest setting 00000001 00000010 Initial setting 00000011 00000100 Lightest setting Machine Parameter D:9 Initial Switch Adjust Usage/Comments Setting Slice level adjustment of Switch 76543210 “Dark”...

  • Page 42: Machine Parameter J:1

    Machine Parameter F:1 Initial Switch Adjust Usage/Comments Setting Adjustment of the scanning Switch 76543210 Settings stretching and squeezing for ADF. (Vertical) 01111111 12.7 % Maximum The plus setting stretch the 00100000 3.2 % image data and the minus setting squeeze it. 00011000 2.4 % Each setting changes by...

  • Page 43: Machine Parameter J:3

    Machine Parameter F:3 Initial Switch Adjust Usage/Comments Setting ADF scanner registration Switch 76543210 Settings adjustment (Horizontal) 01111111 63.5 mm Maximum Adjusts the start point to scan the document. 00000011 1.5 mm 00000010 1.0 mm The plus setting decrease the 00000001 0.5 mm left margin and the minus 00000000...
  • Page 44 Machine Parameter J:1 Initial Switch Adjust Usage/Comments Setting Printer registration Switch 76543210 Settings adjustment (Vertical) at the 01111111 5.3 mm Maximum bypass tray. Adjusts the start point to 00000011 0.13 mm print. 00000010 0.08 mm The plus setting increase the 00000001 0.042 mm top margin and the minus...
  • Page 45 Machine Parameter J:3 Initial Switch Adjust Usage/Comments Setting Printer registration Switch 76543210 Settings adjustment (Horizontal) at the 00001000 4.0 mm Maximum optional second cassette. Adjusts the start point to 00000010 1.0 mm print. 00000001 0.5 mm The plus setting increase the 00000000 0.0 mm left margin and the minus...

  • Page 46: Memory Switch Adjustment

    3.3 Memory Switch Adjustment 3.3.1 Setting the Memory Switches These switches are used to program internal machine parameters. The primary back up battery maintains these settings if power is lost. 1. From standby, press Program key, *, 1. Set Memory Switch /Enter 2.

  • Page 47: Memory Switch A:0 - Dialer

    Memory Switch A:0 - Dialer Initial Switch Adjust Usage/Comments Setting Factory use only Factory use only Factory use only Factory use only DIS detect time after dialing Sets the time DIS signal is detected after dialing a 0: 80 sec number.

  • Page 48: Memory Switch A:5 - Dialer

    Memory Switch A:5 - Dialer Initial Switch Adjust Usage/Comments Setting Factory use only Ring signal detect time Set the time that an incoming ring will not be detected after hanging up. (Fax/Tel Ready mode only.) Switch 6 5 4 0 0 0 100 ms 0 0 1 200 ms...

  • Page 49: Memory Switch B:0 - Transmission

    Memory Switch B:0 - Transmission Initial Switch Adjust Usage/Comments Setting Busy tone detection Sets this switch to “0” if the ring tone of remote unit 0: No is mistaken for a busy signal. 1: Yes Fallback pattern (bps) 2400 4800 7200 9600 14400...

  • Page 50: Memory Switch B:1 - Transmission

    Memory Switch B:1 - Transmission Initial Switch Adjust Usage/Comments Setting The time between reception of CFR and transmission of data When CFR and data overlap due to line echo, increase the interval between CFR and data transmission using this switch. 250 ms 500 ms 750 ms 1000 ms Switch 7 Switch 6...

  • Page 51: Memory Switch B:2 - Transmission

    Determines communication protocol. 0: V.17 1: V.33 Forced received print when Will force a remote Muratec machine with memory transmitting from memory receive capabilities to print directly. This switch will 0: No prevent a memory overflow error at the remote unit.

  • Page 52: Memory Switch B:5 - Transmission

    Memory Switch B:5 - Transmission Initial Switch Adjust Usage/Comments Setting Program individual autodialer Allows individual setting of memory switches B:0 as attributes attribute 1, B:1 as attribute 2, B:2 as attribute 3 and 0: No B:3 as attribute 4 when one-touch and speed dial 1: Yes locations are programmed.

  • Page 53: Memory Switch C:0 - Reception

    Memory Switch C:0 - Reception Initial Switch Adjust Usage/Comments Setting Data error rate Determines the allowable number of erred lines out 0: 10% of total lines received in a document. 1: 20% Pause one second after A 2100 Hz CED signal disables echo suppression in sending CED some telephone equipment.

  • Page 54: Memory Switch D:0 - Reception

    Memory Switch D:0 - Reception Initial Switch Adjust Usage/Comments Setting Number of HDLC end flags Defines the number of HDLC end flags. Switch 7 6 5 4 0 0 0 0 0 0 0 1 0 0 1 0 Initial setting 0 0 1 1 0 1 0 0 0 1 0 1...

  • Page 55: Memory Switch D:2 - Reception

    Memory Switch D:2 - Reception Initial Switch Adjust Usage/Comments Setting EYE-Q slice level Setting this bit to “1” enables memory switch D:2, 0: Disable bits 0-3 and memory switch D:1, bits 0-7 and 1: Enable enables EYE-Q check adjustment. Check EYE-Q Set at 0: Line condition status (EYE-Q) is not 0: No checked after checking TCF.

  • Page 56: Memory Switch E:0 - Scanner

    Memory Switch E:0 - Scanner Initial Switch Adjust Usage/Comments Setting Factory use only Factory use only Factory use only Factory use only Factory use only Factory use only Factory use only Document TX length limit Setting to unlimited will override document jam 0: 3.6 meters sensing.

  • Page 57: Memory Switch G:1 - Remote Reception

    Memory Switch G:1 - Remote reception Initial Switch Adjust Usage/Comments Setting Off-hook / on-hook detect Sets the time interval between the off-hook/on-hook time (remote reception) condition for remote reception. The total time of this time and the time specified in G:6 will be the actual time.

  • Page 58: Memory Switch G:2 - Remote Reception

    Memory Switch G:2 - Remote reception Initial Switch Adjust Usage/Comments Setting Factory use only Factory use only Factory use only CNG detect in Ans/Fax ready When set to “1”, the machine detects the CNG 0: No signal in Ans/Fax ready. 1: Yes Switch-hook time If the switch hook is quickly depressed and...

  • Page 59: Memory Switch G:3 - Remote Reception And Tad Interface

    Memory Switch G:3 - Remote reception and TAD interface Initial Switch Adjust Usage/Comments Setting Adjust silent detection time This switch adjusts the length of silence required for silent detection activation. Switch 7 6 5 4 Time 0 0 0 0 0 sec 0 0 0 1 1 sec...

  • Page 60: Memory Switch G:4 - Remote Reception And Tad Interface

    Memory Switch G:4 - Remote reception and TAD interface Initial Switch Adjust Usage/Comments Setting CNG detect period after TAD Sets the period during which CNG is detected after begins recording ICM the TAD begins recording incoming message. Switch 7 6 5 4 Time 0 0 0 0 0 sec...

  • Page 61: Memory Switch G:5 - Remote Reception

    Memory Switch G:5 - Remote reception Initial Switch Adjust Usage/Comments Setting Adjust the detect time for Increase/decrease the time specified in this switch regarding as the CI signal. from the standard detect time. Determine it in G:5 bit 3 whether increase or decrease. Switch 7 6 5 4 Time 0 0 0 1...

  • Page 62: Memory Switch H:0 - Operation

    Memory Switch H:0 - Operation Initial Switch Adjust Usage/Comments Setting Display error line The number of error lines contained in the received 0: No data will be shown in the LCD. 1: Yes Total line monitor Allows fax communication to be heard through the 0: No monitor speaker.

  • Page 63: Memory Switch H:2 - Operation

    Memory Switch H:2 - Operation Initial Switch Adjust Usage/Comments Setting Factory use only Factory use only Factory use only Factory use only Factory use only Print the transmission time on Determines if printing the communicating duration (in minutes and seconds) on the confirmation report 0: No (RCR).

  • Page 64: All Ram Clear

    3.5 All RAM Clear The All RAM Clear setting will erase all user programmed information, all documents in memory, and reset the memory switches and machine parameters to factory defaults. This feature may also be used to try and clear a machine malfunction or lock up. If possible, when the All RAM Clear is used to reset a malfunction or lock up, it is advisable to print the machine settings, one- touch and speed dial listings to help in reprogramming this information.
  • Page 65 Attribute 1 - Individual Autodialer Setting (Equivalent to Memory Switch B:0) Initial Switch Adjust Usage/Comments Setting Busy tone detection Sets this switch to “0” if the ring tone of remote unit 0: No is mistaken for a busy signal. 1: Yes Fallback pattern (bps) 2400 4800...
  • Page 66 Determines communication protocol. 0: V.17 1: V.33 Forced received print when Will force a remote Muratec machine with memory transmitting from memory receive capabilities to print directly. This switch will 0: No prevent a memory overflow error at the remote unit.
  • Page 67 Attribute 4 - Individual Autodialer Setting (Equivalent to Memory Switch B:3) Initial Switch Adjust Usage/Comments Setting Factory use only Factory use only Factory use only When set at “1”, transmission of the CSI, TSI and CIG signals are disabled. ECM mode Determines ECM mode.

  • Page 68: Unique Switch Adjustment

    3.7 Unique Switch Adjustment 3.7.1 Setting the Unique Switches These switches are used to program internal machine parameters. The primary back up battery maintains these settings if power is lost. 1. From standby, press Program key, *, 4. Set Uniq Switch /Enter 2.

  • Page 69: Unique Switch A:0 - Dialer

    Unique Switch a:0 — Dialer Initial Switch Adjust Usage/Comments Setting Factory use only Congestion tone detection Setting this switch to “0”, ignores telephone line 0: No congestion tones. 1: Yes Ring back tone wait time Sets the time until the ring back tone begins after (seconds) answering an incoming call in the Fax/Tel Ready or 3.0 3.3 3.6 3.9...

  • Page 70: Unique Switch B:6 - Transmission

    Unique Switch b:6 - Transmission Initial Switch Adjust Usage/Comments Setting Available *, # and space Determines if checking the * (asterisk), # (sharp) upon F-code SUB/SEP and space upon F-code SUB/SEP registration. registration 0: No 1: Yes Available *, # and space Determines if checking the * (asterisk), # (sharp) upon F-code communicating and space upon F-code communicating.

  • Page 71: Unique Switch B:8 - Transmission

    Unique Switch b:8 - Transmission Initial Switch Adjust Usage/Comments Setting Factory use only Factory use only Factory use only Factory use only Factory use only Factory use only Factory use only Transmission when disable to Determine the action when disable to detect first detect first NSF in feeder NSF in feeder transmission.

  • Page 72: Unique Switch C:1 - Reception

    Unique Switch c:1 - Reception Initial Switch Adjust Usage/Comments Setting T1 timer adjustment When the unit switches to fax by on-hook transfer, the unit will seize the telephone line and attempt to handshake. Switch 7 5 6 4 Settings 0 0 0 0 0 0 0 1 0 0 1 0 0 0 1 1...

  • Page 73: Unique Switch C:2 - Reception

    Unique Switch c:2 - Reception Initial Switch Adjust Usage/Comments Setting Factory use only Factory use only Factory use only Factory use only Factory use only Receive the junk fax When the block junk fax feature was set to Mode 2 0: Yes and the fax does not receive the TSI signal from the 1: No...

  • Page 74: Unique Switch D:0 - Modem

    Unique Switch d:0 - Modem Initial Switch Adjust Usage/Comments Setting Factory use only Factory use only Factory use only Factory use only Factory use only Factory use only Factory use only Factory use only Unique Switch d:1 - Modem Initial Switch Adjust Usage/Comments...

  • Page 75: Unique Switch D:2 - Modem

    Unique Switch d:2 - Modem Initial Switch Adjust Usage/Comments Setting Factory use only Factory use only Factory use only Factory use only Factory use only Factory use only Factory use only Factory use only Unique Switch d:3 d:5 --- Factory use only Unique Switch d:6 - Modem Initial Switch...

  • Page 76: Unique Switch D:7 - Modem

    Unique Switch d:7 - Modem Initial Switch Adjust Usage/Comments Setting Factory use only Factory use only Factory use only Factory use only Factory use only Factory use only Factory use only Unique Switch d:8 e:1 --- Factory use only Unique Switch e:2 - Scanner Initial Switch Adjust...

  • Page 77: Unique Switch E:7 - Scanner

    Unique Switch e:7 - Scanner Initial Switch Adjust Usage/Comments Setting Factory use only Factory use only Right edge document margin Switch 5 4 3 2 1 0 Settings adjustment upon scanning 0 0 0 0 0 0 0 mm using FBS 0 0 0 0 0 1 1 mm 0 0 0 0 1 0...

  • Page 78: Unique Switch E:8 - Scanner

    Unique Switch e:8 - Scanner Initial Switch Adjust Usage/Comments Setting Factory use only Factory use only Leading edge document Switch 5 4 3 2 1 0 Settings margin adjustment upon 0 0 0 0 0 0 0 mm scanning using FBS 0 0 0 0 0 1 1 mm 0 0 0 0 1 0...

  • Page 79: Unique Switch E:9 - Scanner

    Unique Switch e:9 - Scanner Initial Switch Adjust Usage/Comments Setting Factory use only Factory use only Trailing edge document Switch 5 4 3 2 1 0 Settings margin adjustment upon 0 0 0 0 0 0 0 mm scanning using FBS 0 0 0 0 0 1 1 mm 0 0 0 0 1 0...

  • Page 80: Unique Switch F:0 - Printer

    Unique Switch f:0 - Printer Initial Switch Adjust Usage/Comments Setting Factory use only Smoothes the data scanned in each resolution mode. Factory use only Factory use only Factory use only Factory use only Smoothing in S-Fine resolution in receive mode 0: No 1: Yes Smoothing in Fine resolution...

  • Page 81: Unique Switch F:2 - Printer

    Unique Switch f:2 - Printer Initial Switch Adjust Usage/Comments Setting Factory use only Factory use only LED print head exposure Initial setting is “000000” and 28.65 sec. If you time adjustment for lists, test want to change the exposure time, set this switch patterns and PCL printing within the following range.

  • Page 82: Unique Switch F:6 - Printer

    Unique Switch f:6 - Printer Initial Switch Adjust Usage/Comments Setting Factory use only Factory use only LED print head exposure Initial setting is “000000” and 28.65 sec. If you time adjustment for copies want to change the exposure time, set this switch and receiving documents within the following range.

  • Page 83: Unique Switch G:0 - Remote Reception

    Unique Switch g:0 - Remote reception Initial Switch Adjust Usage/Comments Setting Factory use only Factory use only Factory use only Factory use only Factory use only Use numeric keypad on the Determines if using the numeric keypad on the fax using second phone control panel of the fax using the second phone.

  • Page 84: Unique Switch H:0 - Operation

    Unique Switch g:8 g:9 --- Factory use only Unique Switch h:0 - Operation Initial Switch Adjust Usage/Comments Setting First Dialing symbol when When set to “0”, “ ” will appear first when pressing pressing Dialing Options key Dialing Options key. 0: “...

  • Page 85: Unique Switch H:3 - Operation

    Unique Switch h:3 - Operation Initial Switch Adjust Usage/Comments Setting Priority of consumable order When the drum cartridge has reached its design life, sheet printing or the toner cartridge is empty, the machine prints a consumable order sheet (see unique switch H:3). 1: Print immediately When this switch is set at “0”, the machine does not 0: Print after the current...

  • Page 86: Unique Switch I:7 - Miscellaneous

    Unique Switch i:7 - Miscellaneous Initial Switch Adjust Usage/Comments Setting Factory use only Factory use only Factory use only Factory use only Factory use only Factory use only Factory use only Print last 25-digit of remote Determines if printing the “ ”, followed by the last number on TCR 25-digit of remote number on TCR, when the...

  • Page 87: Unique Switch J:5 - Miscellaneous

    Unique Switch J:5 - Miscellaneous Initial Switch Adjust Usage/Comments Setting Factory use only Factory use only Factory use only Factory use only Factory use only Priority of Printing the Check When set to “1”, A5(Portrait) sized paper will be message on A5(Portrait) given priority to print the check message.

  • Page 88: Printer Maintenance Mode

    3.8 Printer maintenance mode In case of followings, use this mode. When replaced the Fuser unit or Transfer roller. When “Please Call Service” message appear in the LCD, access this mode to determine the cause of the “Please Call Service” error message. When you replace the Fuser unit or Transfer roller, you must set the count of replacement manually To access the printer maintenance modes:...

  • Page 89: Print Service Report

    3. The kind of printer error will be displayed. If happens two or more troubles, the number of troubles is displayed on the right upper of the LCD. For example, when “Heater error” and “Drum Fuse Error” has occurred, the LCD shows 2. Service Call How many troubles Heater Error...

  • Page 90: Life Monitor

    3.11.1 Life Monitor The life monitor displays the current software version, the total number of pages scanned, printed, and transmitted, the number of drums replaced and the total page count on the current drum. Note: The All RAM Clear setting does not clear the life monitor. To clear, see below. 1.

  • Page 91: Printer Test

    3.11.2 Printer Test The Printer Test mode offers seven different test patterns as shown below. Pattern A Pattern B Pattern C Pattern D Pattern E Pattern F Pattern G 1. Press Program key, *, 9, , then press ENTER. Pattern 2.

  • Page 92: Feeder Test

    3.11.3 Feeder test The feeder test discharges all documents in the automatic document feeder at a constant speed and displays the document total in the LCD. 1. Load test documents into the automatic document feeder. 2. Press Program key, *, 9, two times, then press ENTER.

  • Page 93: Print Machine Parameters, Memory Switch And Unique Switch Settings

    3.12 Print Machine Parameters, Memory Switch and Unique Switch Settings This function instructs the unit to print a list of the machine parameter, memory switch and unique switch settings. The list shows the default and current settings for each. After printing, the unit returns to standby. 1.

  • Page 94: Lcd Test

    3.13.3 LCD Test This mode displays two test patterns in LCD. 1. Press Program key, *, B(02). Then press One-touch C(03). LCD Test Pressing START, all dots turn on. Next pressing START, all dots turn off. Finally pressing START, the alphabetical characters are shown in the LCD. ABCDEFGHIJKLMNOPQRST UVWXYZabcdefghijklmn 2.

  • Page 95: Sram Check

    The DRAM on the Main PCB The 8MB Optional Memory PCB (MFX-1200) The first 8MB DRAM on the 24MB Optional Memory PCB (MFX-1600) The second 8MB DRAM on the 24MB Optional Memory PCB (MFX-1600) The third 8MB DRAM on the 24MB Optional Memory PCB (MFX-1600) Then press START.

  • Page 96: Rtc(Real Time Clock) Test

    The machine starts checking and the result(OK/NG) will be shown in the display. For example, if the check area is “0” and one additional memory, you will see: DRAM Check OK:12 3. Press STOP to exit the test mode. 3.13.7 RTC(real time clock) Test This test mode is not applicable to field service of this machine.

  • Page 97: Line Tests

    3.14 Line Tests This mode offers several internal tests and ability to monitor certain unit output functions. Included are relay tests, modem signal output monitoring, and DTMF output monitoring. 1. Press Program key, *, C(03) to enter the test mode. The tests are contained within three main menus.

  • Page 98: Tonal Signal Test

    3.14.2 Tonal Signal Test The tonal signal test permits the unit’s output tones to be monitored. Note: To monitor the tones, an external monitoring device must be connected to the telephone line jack. 1. Press Program key, *, C (03). Board Number? 2.
  • Page 99 19200 bps 3429 baud 4800 bps 21600 bps 7200 bps 24000 bps 9600 bps 26400 bps 12000 bps Note: V.34 is available only for MFX-1600. 14400 bps 16800 bps 19200 bps 21600 bps 24000 bps 26400 bps 28800 bps 31200 bps...

  • Page 100: Dtmf Output Test

    7. To select another tonal signal, repeat steps 4-6. Otherwise, proceed to step 8. 8. To exit the tonal signal test mode, press STOP under not tests. 9. Press STOP again to return to standby mode. 3.14.3 DTMF Output Test The DTMF output test permits the unit’s DTMF tones to be monitored.

  • Page 101: Mirror Carriage Transfer Mode

    3.15 Mirror Carriage Transfer Mode Important: The fax’s mirror carriage is fixed using the four screws at transferring. When installing the fax, remove the four mirror carriage mounting screws and turn the power on. Then perform this mode. 1. Press Program key, *, E(05). Mirror Locked / /Enter 2.

  • Page 102: Print Consumable Order Sheet

    4. Press ENTER to save the distributor’s name and continue. The LCD will show: CUST CODE ;Upper Enter the customer’s code. The customer’s code may be up to 10 characters in length. 5. Press ENTER to save the customer’s code and continue. The LCD will show: CUST NAME ;Upper Enter the customer’s name.

  • Page 103: Dram Clear

    3.19 Clear Optional Data This mode clears all data and all activity journals for optional RS-232C, Printer controller and second phone line. Note: Second phone line is available only for the MFX-1600. 1. Press Program key, *, I (09). Option Data Initial...

  • Page 104: Set Service Code

    3.20 Set Service Code This is the code which, one can protect the life monitor clear operation. If it is not necessary to protect to the life monitor clear operation, abort this operation without entering the service code. 1. Press Program key, *, J (10). Set Service Code Old Passcode :****...

  • Page 105: Jp1, Jp2 Battery Backup

    8. Enter previous value of the toner life, then press ENTER. Fuser Replaced Count 0000000000 9. Enter previous value of the fuser replaced count, then press ENTER. Fuser Life 0000000000 10. Enter previous value of the fuser life, then press ENTER. Transfer Rplcd Count 0000000000 11.

  • Page 106: Update The Software

    3.23 Update the software Here’s instruction to update the software version of the Flash ROM. Important: To update the software, it needs the flash ROM writer and three of the latest versions of EP- ROMs — ROM0, ROM1 and ROM2. 1.

  • Page 107: Section4 Troubleshooting Procedures

    Section4 Troubleshooting Procedures 4.1 Troubleshooting Outline Before troubleshooting a unit check the following: Is the power cord correctly connected to the machine? Is the telephone handset and the telephone line cord connected correctly? Is there paper in the paper cassette? Are all covers closed correctly? Before removing any portions of the machine or making any adjustments be sure the power cord is disconnected from the unit.

  • Page 108: Recording Paper Jam

    4.2 Recording Paper Jam Symptom: Recording paper did not exit paper cassette properly or jam occurred in print area. Suggested corrective action: 1. Verify that the recording paper conforms to the type specified for use in the machine and that has not been damaged or exposed to moisture.

  • Page 109: Document Feeder Multi-Feeding Or Skew

    4.4 Document Feeder Multi-feeding or Skew Symptom: Two or more pages of a multi-page document are fed at once. The document is fed on the skew. Slight skewing may sometimes occur. Suggested corrective action: 1. Verify that the original documents conform to the specifications designed for use in the machine and they are not damaged in any way.

  • Page 110: Cannot Transmit

    4.8 Cannot transmit Symptom: The unit will not transmit Suggested corrective action: 1. Verify the telephone line cord is properly installed and plugged into the correct type of wall jack. 2. Check for dial tone at the unit and wall jack. If no dial tone is present at the unit, check the NCU PCB. 3.

  • Page 111: Clearing Jammed Paper

    4.11 Clearing Jammed Paper If the original document jams 1. If an original document jams in the ADF while scanning the document into the memory for faxing or copying, the LCD will show: Document Jam ContStor Enter/Cancl If you do wish to continue the operation, press ENTER and proceed to step 2. To abort the operation, press CANCEL.

  • Page 112: To Remove The Document

    To remove the document: 1. Open the scanner cover. 2. Lift the original document from the machine. Note: If you cannot remove the original document, open the inner cover as shown at right, then remove the document. 3. Gently close the scanner cover, making sure both sides are snapped down securely. Note: If the original document has become wrinkled or torn, do not re-send it.

  • Page 113: If A Printout Jams Inside Your Machine

    If a printout jams inside your machine To clear a printout jammed inside your machine: Important: Gently close the top cover so that you don’t catch your hands, possibly injuring them. 1. Open the top cover. 2. Open the printer cover. 3.
  • Page 114 4. Remove the jammed paper. Important: The fuser unit becomes very hot. Do not touch the fuser unit when you are removing a paper jam. Note: Avoid getting “unfixed” toner on your hands and clothes. Open the side cover. Pulling up the jam release lever to remove the jammed paper. 5.

  • Page 115: The Image Quality Problems

    4.12. The Image Quality Problems The following provides guidelines for troubleshooting the printer engine and actions to be taken. Before removing any portions of the machine or making any internal adjustments, be sure power to the unit is OFF. Suggested corrective actions should be performed in order as listed. Most conditions can be corrected by performing routine preventative maintenance steps.

  • Page 116: Printout Too Light

    4.12.3 Printout too light Symptom: Printed image is faint or does not print solid. ABCDE Poor development Remove the toner cartridge and shake it a few times to redistribute the toner ABCDE inside. If the problem persists, replace the toner cartridge. ABCDE Replace the High Voltage Unit.

  • Page 117: Uneven Print Density

    4.12.6 Uneven print density Symptom: Image graduates from dark to light across page. Poor development Remove the toner cartridge and shake it a few times to redistribute the toner inside. If the problem persists, replace the toner cartridge. Replace the High Voltage Unit. Clean the LED print head.

  • Page 118: White (Black) Line

    4.12.8 White (Black) Line Symptom: White or black strip appears vertically through image. Poor development ABCDE Replace the Toner Cartridge. Defective Drum ABCDE Replace the Drum Cartridge. ABCDE Improper charging ABCDE Replace the Drum Cartridge. Improper fusing ABCDE Replace the Fusing Unit. Poor image transfer Replace the Image Transfer Unit.

  • Page 119: Lcd Error Messages

    4.13 LCD Error Messages Your fax machine’s LCD messages can help you spot problems. LCD error messages (Alphabetic list) What you see on the LCD What it means/ What to do All Commands In Use Your fax machine has all of its 99 possible delayed commands (automatic redialing counts as one) stored in memory and cannot accept another.
  • Page 120 What it means/ What to do What you see on the LCD Document Stored You tried to erase a batch box which contains at least one document. Erase the document(s), then try again. Drum Near End Your drum will need to be replaced soon. Enter No.
  • Page 121 What you see on the LCD What it means/ What to do Memory Overflow During transmission (or copying), you tried to enter more pages into Start Or Cancel memory than your fax could store. Press START to tell your fax to keep as many pages in memory as possible, or press CANCEL to delete from memory all pages stored during this operation (but not previous operations).
  • Page 122 What you see on the LCD What it means/ What to do Open 1st Side Cover carefully. Please Remove Paper Open 2nd Side Cover Please Remove Paper Open Top/2-Bin Cover Please Remove Paper Remove Bypass Paper Open&Close Top Cover Open&Close ScanCover Either your document wasn’t inserted correctly, or the fax to which you’re Reset Document sending can’t handle the document’s page length.
  • Page 123 What it means/ What to do What you see on the LCD Too Many Characters You attempted to enter too many numbers or other characters in the current operation. Press CANCEL to delete the extra characters, then try again. You may wish to review the operation’s appropriate instructions.

  • Page 124: Error Codes

    4.14 Error Codes If an error occurs during a communication, a check message will be printed. The following provides an explanation of the information found on check messages. A possible solution to the problem The date and time of the attempted communication The sending location (if the remote fax has a Location ID) The number of pages which got through before the error terminated the call The error code...

  • Page 125: Transmission Errors

    R.4.4 The receiving fax machine has reached its memory capacity. R.5.1 DCN was received instead of RR during ECM communication. R.5.2 Line noise or other problems prevented ECM reception. R.8.4 A compatibility error occurred. R.8.10 Line noise or other problems prevented line probing. R.8.11 The fax machine timed out while waiting for the retrain signal.

  • Page 126: Communication Error Messages

    Communication Error Messages The error messages on Check Message printouts indicate the following: Here’s a brief summary: Error Message Possible Meanings Check condition of remote fax. Remote machine malfunctioned No handshake signals from remote machine Wrong phone number reached Repeat transmission. Poor phone line conditions prevented communication No handshake signals from remote machine...

  • Page 127: Service Call Error

    4.15 Service Call Error When certain machine problems occur these message will appear in the LCD. 4.15.1 Call For Service Symptom: “Call For Service” is in the LCD. Suggested corrective action: 1. Verify the lamp turns on when the book cover open and close. 2.
  • Page 128 The errors messages and an explanation of each are outlined below. Heater Error Symptom: fuser heater malfunction. Suggested corrective action: 1. Check the connectors from the power supply to the main control PCB and to the fuser unit. 2. Check the heater lamp. If it comes on, see step 3; if it does not, see step 5. 3.
  • Page 129 RX Motor Error Symptom: RX motor malfunction Suggested corrective action: 1. Verify the RX motor rotates when the power is on. 2. Check the connection between RX motor and the Connect Printer PCB (P1308). (See page 2-1.) 3. Replace the RX motor if it doesn’t rotate. 4.

  • Page 130: Lcd Failure

    4.16 LCD Failure Symptom: No display in the LCD. Suggested corrective action: 1. Verify that the power cord is correctly connected and the power switch is ON. 2. Check for a blown fuse or open circuit on the unit’s internal power supply. 3.

  • Page 131: Cleaning The Unit

    4.18 Cleaning the Unit Use a mild cleaning solution on a lint-free cloth to wipe the machine’s cover, handset and paper cassette tray. Never spray cleaner directly onto the fax machine as the spray could damage components inside the fax. Curing frequent jams in the ADF If you’re having trouble with getting your original documents to feed properly, try this procedure: 1.

  • Page 132: Cleaning The Fbs Glass, Contact Glass And White Pad

    Cleaning the FBS glass, Contact glass and white pad 1. Open the platen cover. 2. Get a soft, lint-free cloth and moisten it with isopropyl alcohol. Important: Make sure the cloth doesn’t have any rough areas. Otherwise, it could scratch the glass surface of the FBS.

  • Page 133: Section5 Maintenance & Adjustment

    Section5 Maintenance & Adjustment 5.1 MAINTENANCE SCHEDULE .......................5-2 5.2 RE/DISASSEMBLE..........................5-3 5.2.1 Covers ............................5-5 5.2.2 PCBs............................5-13 5.2.3 Sensors ............................5-23 5.2.4 Scanning section .........................5-24 5.2.5 Printer section..........................5-36 5.3 ADJUSTMENT............................5-48 5.3.1 Adjustment of Retard roller pressure...................5-48...

  • Page 134: Maintenance Schedule

    5.1 Maintenance schedule Scanner Section Maintenance Cycle (pages) Reference Parts Name Page Clean Replace — 5-25 Separator roller — 5-26 Retard roller — — 5-27 to 5-30 Other rollers Clean if it — — Contact glass & FBS glass dirty Clean if it —...

  • Page 135: Re/Disassemble

    5.2 Re/Disassemble Before disassembling, disconnect the power cord and line cord. 5.2.1 COVERS............................5-5 FRONT COVER .............................5-6 REAR COVER ............................5-6 TOP FRONT COVER / TOP RIGHT COVER / TOP LEFT COVER ............5-7 TOP REAR COVER ..........................5-7 HARNESS HOLDER ..........................5-7 TX COVER .............................5-8 TX SIDE COVER F..........................5-8 TX SIDE COVER R ..........................5-9 EXIT TRAY .............................5-9...
  • Page 136 ADF PERMIT SENSOR (APS) ......................5-28 FEED ROLLER B ..........................5-29 EXIT ROLLER ............................5-30 HOME SENSOR / END SENSOR......................5-32 FBS MOTOR ............................5-32 SCANNER ASSEMBLY........................5-33 KNOB..............................5-35 5.2.5 PRINTER SECTION ........................5-36 COVER SWITCH..........................5-36 CASOP ..............................5-36 SOLENOID ............................5-37 RX MOTOR ............................5-37 DRIVE GEAR ASSEMBLY ........................5-38 TOS ..............................5-38 PICK UP ROLLER MP..........................5-39 HPES ..............................5-39...

  • Page 137: Covers

    5.2.1 Covers Tx side cover F Platen cover Bypass tray One-touch cover Right cover Panel cover Jam access cover Front cover Cover opener Harness holder Top rear cover Top left cover Contact glass Top right cover Top front cover Pane Tx side cover R Tx cover Rx exit cover...

  • Page 138: Front Cover

    FRONT COVER 1. Open the top cover. 2. Remove the two front cover mounting screw. 3. Remove the FRONT COVER. REAR COVER 1. Open the top cover. 2. Remove the five rear cover mounting screws. 3. Disconnect the speaker connector and remove the REAR COVER.
  • Page 139 TOP FRONT COVER / TOP RIGHT COVER / TOP LEFT COVER 1. Open the platen cover. 2. Remove the screw covers. 3. Remove the three top front cover mounting screws, and then remove the TOP FRONT COVER. 4. Remove the two top right cover mounting screws, and then remove the TOP RIGHT COVER. 5.

  • Page 140: Tx Cover

    TX COVER 1. Open the scanner cover. 2. Remove the four Tx cover mounting screws. 3. Remove the TX COVER. Tx cover TX SIDE COVER F 1. Open the platen cover. 2. Remove the Tx side cover F mounting screw. 3.
  • Page 141 TX SIDE COVER R 1. Open the platen cover. 2. Remove the three Tx side cover R mounting screws. 3. Remove the TX SIDE COVER R. Tx side cover R EXIT TRAY 1. Open the cassette. 2. Remove the three exit tray mounting screws. 3.
  • Page 142 OPTION COVER A 1. Remove the option cover A mounting screw. 2. Remove the OPTION COVER A. Option cover A RX EXIT COVER 1. Remove the EXIT TRAY. 2. Remove the TOP LEFT COVER. 3. Remove the OPTION COVER A. 4.

  • Page 143: Right Cover

    RIGHT COVER 1. Remove the FRONT COVER. 2. Remove the REAR COVER. 3. Remove the two right cover mounting screws. 4. Slide the line cover and disconnect the harnesses of the TOS sensor and the HPES sensor. 5. Then remove the RIGHT COVER. Right cover Line cover COVER OPENER...
  • Page 144 PANEL COVER Perform the procedure of step 1 through 2 in “PANEL A, B, C and LCD,” page 5-17. PLATEN COVER Perform the procedure of step 1 through 5 in “CONNECT SCANNER PCB,” page 5-18. BOTTOM CORNER COVER Perform the procedure of step 1 through 2 in “CONNECT SCANNER PCB,” page 5-18. BYPASS TRAY Refer to page 5-47.

  • Page 145: Pcbs

    5.2.2 PCBs CCD PCB Connect ADF PCB Inverter PCB Connect scanner PCB Battery PCB Main control PCB Panel B PCB Connect printer PCB Panel A PCB Panel C PCB HVPS MAIN CONTROL PCB Note: Before changing the main control PCB, back up the user data (such as one-touch dial numbers). Confirm the JP1 and JP2 on the main control PCB are set to ON.

  • Page 146: Ncu Pcb

    NCU PCB 1. Remove the EXIT TRAY. 2. Remove the two NCU PCB mounting screws and one F.G. wire mounting screw. 3. Disconnect all connectors on the NCU PCB. 4. Remove the NCU PCB. Shield plate NCU PCB MODULAR PCB 1.
  • Page 147 POWER SUPPLY UNIT (PSU) 1. Remove the REAR COVER. 2. Remove two fan motor mounting screws, and then remove the FAN MOTOR. 3. Remove the duct mounting screw, and then remove the DUCT. Duct Fan motor 4. Disconnect two connectors on the PSU. 5.
  • Page 148 HIGH VOLTAGE POWER SUPPLY (HVPS) 1. Open the top cover. 2. Remove the FRONT COVER. 3. Disconnect the connector on the HVPS and remove five HVPS mounting screws, then remove the HVPS. High voltage power supply CONNECT PRINTER PCB 1. Remove the REAR COVER. 2.
  • Page 149 PANEL A, B, C and LCD 1. Remove the TOP FRONT COVER. 2. Remove three panel cover mounting screws, and then remove the PANEL COVER. Panel cover 3. Disconnect two connectors between PANEL A and B, PANEL B and C. 4.

  • Page 150: Bottom Corner Cover

    7. Remove two LCD support mounting screws, and then remove the LCD. LCD support LCD spacer CONNECT SCANNER PCB 1. Remove the TOP FRONT COVER, THE TOP RIGHT COVER and the TOP LEFT COVER. 2. Remove the bottom corner cover mounting screw, and then remove the BOTTOM CORNER COVER. 3.
  • Page 151 4. Open the top cover and remove the Hinge screw as shown. Hinge screw 4. Remove the harness holder mounting screw, and then remove the HARNESS HOLDER. 5. Remove the PLATEN COVER assembly. Platen cover assembly Harness holder 6. Remove two screw covers. Then remove four top rear cover mounting screws, and then remove the TOP REAR COVER.

  • Page 152: Battery Pcb

    7. Disconnect all connectors on the connect scanner PCB, and then remove the CONNECT SCANNER PCB. Connect scanner PCB BATTERY PCB 1. Perform the procedure of step1 through 6 in “CONNECT SCANNER PCB,” page 5.18. 2. Disconnect the connector on the BATTERY PCB and remove the BATTERY PCB mounting screw, then remove the BATTERY PCB.

  • Page 153: Inverter Pcb

    INVERTER PCB 1. Remove the TOP FRONT COVER and the TOP RIGHT COVER. 2. Remove the FBS glass. 3. Remove two LENS COVER mounting screws, and then remove the LENS COVER. 4. Disconnect two connectors on the INVERTER PCB and remove two INVERTER PCB mounting screws, then remove the INVERTER PCB.

  • Page 154: Connect Adf Pcb

    CONNECT ADF PCB 1. Remove the TX SIDE COVER R. 2. Disconnect all connectors on the CONNECT ADF PCB. 3. Remove the ground wire. 4. Remove two CONNECT ADF PCB mounting screws, and then remove the CONNECT ADF PCB. Ground wire Connect ADF PCB 5-22...

  • Page 155: Sensors

    5.2.3 Sensors TXIL COVER SW DRUM SW HOME HPES CASOP JCOP TXIL Refer to “TXIL(ADF), DS1/DS2,” page 5-25. Refer to “TOS,” page 5-38. HOME Refer to “HOME sensor / END sensor,” Refer to “PDS/Thermistor,” page 5-41. page 5-32. Refer to “PES,” page 5-42. Refer to “HOME sensor / END sensor,”...

  • Page 156: Scanning Section

    5.2.4 Scanning section GEAR 16/36 SEPARATOR GEAR 22 TENSION PULLEY IDLER GEAE 48 PULLEY 50/17 PULLEY 50/17 GEAR 26/30 EXIT GEAR 24 TENSION PULLEY PULLEY 17 BELT INSTALLATION OF ADF SECTION FBS Motor BELT INSTALLATION OF FBS SECTION 5-24...
  • Page 157 TXIL (ADF) / DS1 / DS2 1. Remove the TX COVER. 2. Remove the sensor you want to remove. TXIL(ADF) SEPARATOR ROLLER ASSEMBLY 1. Remove the TX COVER. 2. Remove the E-ring, and then remove the separator gear 22. 3. Remove two E-rings, and then remove the SEPARATOR ROLLER Assembly. Separator gear 22 Separator roller assembly.
  • Page 158 RETARD ROLLER / TORQUE LIMITER 1. Open the Scanner Cover. 2. Remove the RETARD COVER. 3. Remove the RETARD ROLLER Assembly. Retard cover Retard roller assembly 4. Remove two E-rings, and then remove the TORQUE LIMITER with the bracket. Torque limiter 5-26...

  • Page 159: Adf Motor

    ADF MOTOR 1. Remove the TX SIDE COVER R. 2. Remove SPRING C, then remove seven motor bracket mounting screws. 3. Remove the MOTOR BRACKET and ADF MOTOR. Motor bracket Spring C Pulley 50/17 G26 FEED ROLLER A 1. Remove the TOP SIDE COVER R and F. 2.

  • Page 160: Adf Permit Sensor (Aps)

    7. Remove the RETARD COVER, RETARD ROLLER assembly and TORQUE LIMITOR. 8. Remove the FEED ROLLER A from the INNER GUIDE A assembly. Inner guide A assembly Feed roller A ADF PERMIT SENSOR (APS) 1. Remove the TX SIDE COVER F and R. 2.

  • Page 161: Feed Roller B

    4. Remove two INNER GUIDE B mounting screws, and then remove the INNER GUIDE B. 5. Release three tabs, and then remove the APS. Inner guide B FEED ROLLER B 1. Remove the TX SIDE COVER R and F. 2. Remove the ADF MOTOR. 3.

  • Page 162: Exit Roller

    EXIT ROLLER 1. Remove the TX SIDE COVER R. 2. Remove two E-rings, and then remove the EXIT GEAR 24 and the Bearings. Exit gear 24 3. Open the Platen Cover. Remove two PLATEN SHEET mounting screws, and then remove the PLATEN SHEET as shown.
  • Page 163 4. Remove five PLATEN STAY B mounting screws, and then remove the PLATEN STAY B. Platen stay B 5. Remove two PRESS SPRING D. 6. Remove the EXIT ROLLER. Exit roller 5-31...

  • Page 164: Home Sensor / End Sensor

    HOME SENSOR / END SENSOR 1. Remove the TOP FRONT COVER, THE TOP RIGHT COVER and the TOP LEFT COVER. 2. Remove the PANE and the CONTACT GLASS. 3. Remove the HARNESS COVER C mounting screw, and then remove the HARNESS COVER C. 4.

  • Page 165: Scanner Assembly

    7. Loosen the REAR ANGLE mounting screw. Remove three FBS MOTOR BRACKET mounting screws. Remove the BELT. Remove the FBS MOTOR with the bracket. Rear angle FBS motor brackect FBS Motor SCANNER ASSEMBLY 1. Remove the TOP FRONT COVER, THE TOP RIGHT COVER and the TOP LEFT COVER. 2.
  • Page 166 6. Remove the BELT RETAINER mounting screw. 7. Remove two LENS COVER mounting screws, and then remove the Flat Cable from the CCD PCB. Lens cover Belt retainer CCD PCB Flat cable 8. Slide out the GUIDE ROD as shown below. Then remove the SCANNER ASSEMBLY. Guide rod Scanner assembly 5-34...

  • Page 167: Knob

    KNOB 1. Open the TOP COVER. 2. Remove the SPRING. 3. Remove the small screw with a precision screwdriver. 4. Pull out the KNOB. Knob Spring 5-35...

  • Page 168: Printer Section

    5.2.5 Printer section COVER SWITCH 1. Remove the REAR COVER. 2. Remove the CONNECT PRINTER PCB. 3. Remove two COVER SWITCH mounting screws, and then remove the COVER SWITCH. Cover switch CASOP 1. Remove the REAR COVER. 2. Remove the CONNECT PRINTER PCB. 3.

  • Page 169: Solenoid

    SOLENOID 1. Remove the REAR COVER. 2. Remove the CONNECT PRINTER PCB. 3. Remove the SOLENOID mounting screw, and then remove the SOLENOID. Solenoid RX MOTOR 1. Remove the REAR COVER. 2. Remove the CONNECT PRINTER PCB. 3. Remove the PSU. 4.

  • Page 170: Drive Gear Assembly

    DRIVE GEAR ASSEMBLY 1. Perform the procedure of step 1 through 3 in “RX MOTOR,” page 5.37. 2. Remove the SOLENOID. 3. Remove the four DRIVE GEAR Assembly mounting screws, then remove the DRIVE GEAR Assembly. Drive gear assembly 1. Open the TOP COVER. 2.

  • Page 171: Pick Up Roller Mp

    PICK UP ROLLER MP 1. Remove the FRONT COVER, the REAR COVER and the RIGHT COVER. 2. Remove the bearing, and then remove the PICK UP ROLLER MP. Pick up roller MP HPES 1. Remove the FRONT COVER, the REAR COVER and the RIGHT COVER. 2.

  • Page 172: Image Transfer Roller

    IMAGE TRANSFER ROLLER 1. Remove the Toner Cartridge and the Drum Cartridge. 2. Remove the IMAGE TRANSFER ROLLER with TRANSFER BRACKET using the precision screwdriver as shown. Image transfer roller FIXING UNIT 1. Remove the toner cartridge and the drum cartridge. 2.

  • Page 173: Pds / Thermistor

    PDS / Thermistor 1. Remove the FIXING UNIT. 2. Remove the FIXING UNIT COVER, and then remove the PDS or the thermistor. Fxing unit cover Themistor EXIT ROLLER P 1. Remove the FIXING UNIT. 2. Disassemble the FIXING UNIT to remove the EXIT ROLLER P. Note: Do not bend the PLATE SPRING at removing or attaching the EXIT ROLLER P.

  • Page 174: Pes

    1. Pull out the cassette completely. 2. Remove the PES mounting screw under the cassette, and then remove the PES. Disconnect the connector. PAPER PICK UP ROLLER 1. Pull out the cassette completely. 2. Pull out the pick up roller. Paper pick up roller 5-42...

  • Page 175: Feed Roller Bp

    FEED ROLLER BP 1. Remove the FRONT COVER, the REAR COVER and the RIGHT COVER. 2. Remove four MP bracket mounting screws, and then remove the MP BRACKET. 3. Remove the Feed B Bearing, and then slide out the FEED ROLLER BP. MP bracket Feed roller BP 5-43...

  • Page 176: Feed Roller Ap

    FEED ROLLER AP 1. Remove the REAR COVER and FRONT COVER. 2. Remove the POWER SUPPLY UNIT. 3. Remove the CONNECT PRINTER PCB. 4. Remove the DRIVE GEAR ASSEMBLY. 5. Remove the HVPS. 6. Remove the MAIN FRAME mounting screws. Main frame 7.

  • Page 177: Pss

    1. Remove the toner cartridge and the dram cartridge. 2. Remove the screw, and then remove the PRESS SPRING B. Remove the RELEASE LEVER and the PRESS ROLLER BP. 3. Remove the PSS COVER and remove the screw. Pull out the PSS and disconnect the connector. Release lever Press spring B Press roller BP...

  • Page 178: Led Print Head

    LED PRINT HEAD 1. Open the printer cover. 2. Remove the E-rings on the both side and pull out the LED print head. Disconnect two connectors. LED print head JCOP 1. Open the Side cover. 2. Disconnect the connector of the JCOP 3.

  • Page 179: Bypass Tray

    BYPASS TRAY 1. Open the Side cover. 2. To remove the BYPASS TRAY, release the tab at the front side of the BYPASS TRAY first, then release the other. Bypass tray 5-47...

  • Page 180: Adjustment

    5.3 Adjustment 5.3.1 Adjustment of Retard roller pressure When the bad document transportation or document separation is occurs even if the rollers dose not wear or uncleanness, adjust the Retard roller pressure. Insert the precision screwdriver into the hole of the Inner guide A as illustration. Then turn the separation pressure adjustment screw with referring the following table.

  • Page 181: Section 6 Options

    Options 6.1 Memory Upgrade An optional 8 MB document memory upgrade is available for the MFX-1200. An optional 8 MB or 24 MB document memory upgrade is available for the MFX-1600. Packaging contents: (1) Memory PCB ....... 1 (2) Spacer ........1 Installation 1.
  • Page 182 Approx. 650 pages 8 MB + 8MB Approx. 650 pages plus 680 pages 8 MB + 24 MB Approx. 650 pages plus 2040 pages (MFX-1600 only) Note: Using the ITU-T Test Document 1 to a Muratec fax machine with normal resolution.

  • Page 183: Attaching An Optional Handset

    6.2 Attaching an optional handset Packaging contents: (1) Telephone handset (with curl cord) ....1 (2) Handset holder ..........1 (3) Cord holder............. 1 (4) Screw ............. 2 Installation 1. Turn the fax machine off and remove the power cord and telephone line cord. 2.

  • Page 184: Rs-232C Interface

    6.3 RS-232C interface Packaging contents: (1) RS-232C PCB ..........1 (2) Connector PCB ..........1 (3) Bracket ............1 (4) Connection cable..........1 (5) One screw ............1 (6) Ferrite core ............. 1 (7) Operating instructions ........1 Installation 1. Turn the fax machine off. 2.
  • Page 185 5. Open the top cover. 6. Remove five mounting screws holding the rear cover in place. Then remove the rear cover. 7. Remove the shield plate. 8. Connect the RS-232C PCB assembly to the Main control PCB with the connection cable as shown below: (Connect the cable to the P14D connector on the main PCB.) 9.

  • Page 186: Rs-232C Interface Cable

    RS-232C interface cable The RS-232C port on your newly installed RS-232C interface has a DB-25 (standard 25-pin serial) female receptacle which accepts a male DB-25 cable plug. Your computer’s port may have either a DB-25 or DB- 9 (9-pin) receptacle. If necessary, see the chart below for detailed information on the pin assignment for your fax machine’s RS232C port.

  • Page 187: Page Counter

    6.3 Page Counter The mechanical counter shows the total number of pages the machine prints. Note: This device counts up to 999,999 pages. If more pages are printed, the counter resets to zero and begins counting the new pages from that point. Packaging contents: (1) Mechanical Counter ......

  • Page 188: Only For Mfx-1600)

    6.4 AL-200 (only for MFX-1600) Packaging contents: (1) Second Phone Line Module — Includes the NCU and Modem PCBs ....1 (2) Screws.........................4 (3) Connection cable....................1 (4) Telephone line cord.....................1 (5) Second Phone Line Module operating instructions ..........1 Installation Note: Turn off the fax machine before proceeding.
  • Page 189 5. Remove the ground wire mounting screw on the Second phone line module. Then remove the ground wire. Note: Keep the ground wire to re-attach it in step 13. 6. Remove two NCU PCB mounting screws and release two tabs as shown. Then remove the NCU PCB from the bottom chassis of the second phone line module.
  • Page 190 9. Re-attach the NCU PCB and the Modem PCB to the bottom chassis using two screws and six tabs. 10.Use the screws to re-attach the four angle plates to the bottom chassis. 11.Plug the connection cable into the P14A connector on the Main control PCB. Remove the mounting screw on the lower left of the shield plate.
  • Page 191 14.Re-attach two ground wire to the Second phone line module’s bottom chassis using the screw. Plug the connection cable into the P1(IN) connector on the Second phone line module’s Modem PCB. 15.Use the four screws to re-attach the second phone line module cover. 16.Plug one end of the telephone line cord into the LINE 2 jack found on the second phone line module.

  • Page 192: Packaging Contents

    6.5 OP-100/NP-200 Packaging contents: Here’s what should be in the OP-100 package: 1. Printer Control PCB ........................1 2. Printer PCB Bracket........................1 3. Operating instructions........................1 4. Ferrite core ...........................1 5. Screws ............................3 6. Connection cable A with Ferrite core....................1 7. Connection cable B........................1 8.

  • Page 193: Attaching The Op-100 (And Np-200)

    Attaching the OP-100 (and NP-200) Note: Make sure to turn off the fax machine before proceeding the following steps. 1. Attach the BRACKET to the PRINTER CONTROL PCB using the hexagonal head screws. Note: The OP-100 can attach the DIMM on the board for memory upgrade. The DIMM which have the following specifications can be attached: •...
  • Page 194 2. Remove the REAR COVER and OPTION COVER A. 3. Remove the SHIELD PLATE. 4. Remove the CABLE CAP from the CONNECTION CABLE A. Then connect the CONNECTION CABLE A to the CON2 connector on the PRINTER CONTROL PCB. 5. Connect the CONNECTION CABLE B to the CON1 connector on the PRINTER CONTROL PCB. 6.
  • Page 195 9. Insert the PRINTER CONTROL PCB (and NIC PCB) completely and then secure it using a screw. 10.Re-attach the SHIELD PLATE. 11. Re-attach the REAR COVER. 12. Cut out the rectangular connector space for OP-100 on the OPTION COVER A. Then attach the OPTION COVER A.

  • Page 196: Installing The Printer Driver

    14. Snap the plug’s wire clips onto the printer cable. 15. Connect the other end of the printer cable to the computer’s parallel port. 16. If using the NP-200, connect the printer to the network by using the network cable. EtherNet port Network cable (10/100Base-T twist pair cable)

  • Page 197: Attaching The 2-Bin Tray

    6.6 Attaching the 2-Bin tray Packaging contents: (1) 2-Bin unit (with connection cable) ...............1 (2) Screws.........................4 (3) Paper tray for the 2-Bin unit ................1 Installation 1. Remove the REAR COVER. 2. Remove the TOP LEFT COVER. 3. Remove the OPTION COVER A. 4.
  • Page 198 10. And then secure the 2-Bin tray using the four screws. 11. Re-attach the PCB SHIELD. 12. Re-attach the RX EXIT COVER A. RX exit cover A 13 Re-attach the EXIT TRAY, TOP LEFT COVER, OPTION COVER A, PCB SHIELD and REAR COVER.

  • Page 199: Top Front Cover / Top Right Cover / Top Left Cover

    <References> REAR COVER 1. Open the top cover. 2. Remove the five rear cover mounting screws. 3. Disconnect the speaker connector and remove the REAR COVER. TOP FRONT COVER / TOP RIGHT COVER / TOP LEFT COVER 1. Open the platen cover. 2.

  • Page 200: Exit Tray

    OPTION COVER A 1. Remove the option cover A mounting screw. 2. Remove the OPTION COVER A. Option cover A EXIT TRAY 1. Open the cassette. 2. Remove the three exit tray mounting screws. 3. Remove the EXIT TRAY. Exit tray 6-20...

  • Page 201: Rx Exit Cover

    RX EXIT COVER 1. Remove the EXIT TRAY. 2. Remove the TOP LEFT COVER. 3. Remove the OPTION COVER A. 4. Remove the Rx exit cover mounting screw, and then remove the RX EXIT COVER. Rx exit cover 5. Separate the RX EXIT COVER A FROM B. Rx exit cover B Rx exit cover A 6-21...

  • Page 202: Second Paper Cassette

    6.7 Second paper cassette Packaging contents: (1) Second cassette (2) Two screws Installation 1. Turn off your fax machine. 2. Remove six mounting screws holding the rear cover of the second cassette in place. Then remove the rear cover of the second cassette. 3.
  • Page 203 5. Release the tab of the harness door under the machine, and then remove the harness door. 6. Put the machine on the second cassette. 7. Pass the harness and the ground wire of the second cassette through the harness door. Connect the harness to the connector (P17) on the Main control PCB.
  • Page 204 9. Re-attach the rear cover of the machine using three mounting screws except two screws at the rear side. Note: Do not forget to connect the speaker connector when attaching the rear cover of the machine. 10 Re-attach the rear cover of the second cassette using two screws (3 10 mm) included in the option cassette box and six mounting screws (3 8 mm) as shown in the illustration.

  • Page 205: Setting Of The Paper Size

    Setting of the Paper Size Default setting: USA version: Letter, Other version: A4 When you install the second cassette, you must set the paper size for it. 1 Press Program key, B, 1, 0, 1, ENTER. The LCD shows: 1st Cassette 1st Cassette :Ltr / /Enter...

This manual is also suitable for:

Mfx-1200

Table of Contents
