3.22 Printer diagnostic mode

This mode can confirm the operation of each parts of the printer section.
1. Press MENU, *, 2, 3.
Fan Full :OFF
/ /Enter
Clutch1 :OFF
/ /Enter
ALL OFF :OFF
/ /Enter
2. Select the device you want to set to ON using cursor key.
3. Press ENTER to toggle the ON and OFF.
Fan Full :Turn the fan motor with full power
Rx Motor :Turn the Rx motor
Dup Motor :Turn the Duplex motor
Clutch 1 :Turn the clutch of 1st cassette
Clutch 2 :Turn the clutch of 2nd cassette
Reg Clutch :Turn the Regist clutch
ALL OFF :Turn the all device to off
4. Press RESET to exit.

3.23 Network service mode

This mode is available only when the optional network board has been installed.
This mode provides the following three items:
•
Display the sum-check of internet fax board
•
Clear the Administrator's information (Not available for this machine)
•
All clear the registered parameters of the optional Internet fax board

3.23.1 Display the server sum-check

1. Press MENU, *, 2, 4.
2. Press ENTER. The machine displays the Sum check.
Sum check :
3. Press RESET to return to standby mode.

3.23.2 Clear the Administrator's information

This mode is no available for this machine.

3.23.3 All clear the registered parameters of the network board

You can clear all the data of network settings like IP address, Subnet Mask or Default Gateway.
1. Press MENU, *, 2, 4,
2. Press ENTER.
Clear Server Data
Yes → Enter
3. Press ENTER. The information will be cleared.
Note: To finish the operation without performing initialization, press CANCEL.
Rx Motor
Clutch2
.
3-117
