Lens Type
Focal Length
Angle View
Lens Iris Control
Image Sensor
Minimum Illumination
Scanning Mode
SNR
Dynamic Range
(Digital WDR)
Electronic Shutter
IR LED
White LED (alarm
supported model only)
Illumination Sensor
IR Working Distance
Compression Algorithm
Compression
Resolution
Bitrate Control
Maximum Frame Rate
(images per second)
Multistream
Compression Algorithm
i
It is supported for audio supported model only.
Specifications
Motorized vari-focal lens
F1.2, f=3.0 mm to 9.0 mm
H: 120.0° (Wide) to 37.0° (Tele)
V: 62.0° (Wide) to 20.0° (Tele)
DC auto iris
1/2.8" CMOS
IR LED Off: 0.5 Lux, IR LED On: 0 Lux
Progressive scan
31.2 dB or higher
74.7 dB or higher
Auto
LED x 42 (850 nm) (LED x 24 for alarm supported model)
LED x 6
Yes
30 m (outdoor)
H.264, M-JPEG (Four levels)
CIF (352x240), 4CIF (704x480), 720p (1280x720), 1080p (1920x1080)
H.264 –CBR / VBR (up to 12 Mbps)
30 ips @ 1080p + 4 ips @ 1080p
Primary, Secondary, Tertiary
G.726 (16KHz), G.711 μ – Law (8KHz)
Specifications are subject to change without notice.
LENS
CAMERA
VIDEO
i
AUDIO
Network Camera
51
