Syscom Video Direct IP Operation Manual page 58

Operation Manual
i
Video Output
ii
Audio Input
ii
Audio Output
iii
Alarm Output
Network Connectivity
i
It is intended for video preview while adjusting the camera.
ii
It is supported for audio supported model only.
iii
It is supported for alarm supported model only.
i
Video Output
ii
Audio In/Out
iii
Alarm Out
Ethernet Port
i
It is intended for video preview while adjusting the camera.
ii
It is supported for audio supported model only.
iii
It is supported for alarm supported model only.
Dimensions Ø x H
(
Shipping Dimensions
(W x H x D)
Unit Weight
Shipping Weight
Operating Temperature
Operating Humidity
Power Supply
Power Consumption
Approval
52
INPUTS/OUTPUTS
1 Composite, 1 Vp-p
1 line in
1 line out
1 relay out, NO only, 0.3A @ 125 VAC, 1A @ 30 VDC
10/100 Mbps Ethernet
CONNECTORS
BNC
Φ 3.5 audio jack
Wires
RJ-45
12.70" x 3.56 x 3.56" (322.7mm x 90.5mm x 90.5mm)
)
14.0 " x 5.2" x8.5" (355mm x 132mm x 217mm)
2.6 lbs. (1.17kg)
4.3 lbs. (1.94kg)
-4°F to 122°F (-20°C to 50°C)
0% to 90%
12 VDC, PoE (Power over Ethernet) (IEEE 802.3af, Class 3)
Max. 7.2W
FCC, CE, IP66, IK10
Specifications are subject to change without notice.
GENERAL
