SPECIFICATIONS

Power
Power source
Power consumption
Sensor Information
Image sensor
Chip size
Picture element
Scanning system
Scanning frequency
Sync system
Electronic shutter
Temperature / Humidity
Video
Signal format
Resolution
Minimum illumination
Video output
S/N ratio
BLC size
Sync level
Electronic iris
Auto iris
BLC
AGC
DC iris level
Connectors & Mechanical
Video output
Power input
Auto iris connector
Lens mount
Mounting hole
Dimensions
Weight
12V DC
Max. 4 Watts
1/3" CCD (SONY)
6.0mm (H) x 4.96mm (V)
Standard: 510 (H) x 492 (V) EIA
500 (H) x 582 (V) CCIR
High: 768 (H) x 494 (V) EIA
752 (H) x 582 (V) CCIR
2:1 interlace
15.75 KHz, 60 Hz EIA
15.625 KHz, 50 Hz CCIR
Internal
1/60 ~ 1/100,000 sec EIA
1/50 ~ 1/100,000 sec CCIR
14º F to 122º F (-10º C to 50º C), < 96%
525 lines EIA / 625 lines CCIR
Standard: 380 TV lines / High: 570 TV lines
0.08 Lux
1.0Vp-p, 75 ohms
50dB (AGC OFF)
40% center
40 IRE(EIA), 300mV(CCIR)
On/Off selectable
Video / DC selectable
On fixed
On/Off selectable
Adjustable
BNC connector
3-pin terminal block at 12V DC model
4-pin mini din
C or CS mount
1 / 4" - 20 UNC top and bottom
2.4W x 2.1H x 5.0D" (62W x 54H x 127D mm)
225g at 12V DC
