Summary of Contents for Syscom Video IR Bullet Network Camera
- Page 1 Quick Installation Guide IR Bullet Network Camera Please read this manual thoroughly before use, and keep it handy for future reference.
-
Page 2: Installation Steps
Quick Installation Guide 1. Description The Network Camera supports the network service for a sensor image with progressive scan, which can be monitored on a real-time screen regardless of distances and locations. By using its dedicated program, many users are able to have an access to the Network Camera at once or a single user can monitor various network cameras at the same time. - Page 3 Quick Installation Guide • Connection Cable Name Description Power Cable Cable for Power source (DC 12V) Ethernet Cable Cable for Ethernet (POE) Camera Dimension See the diagrams below for the exact dimension Dimensions Unit: mm Base Installation(Cable through the wall or ceiling with the mount base) ...
-
Page 4: Installation
Quick Installation Guide 2. Installation 2.1 Connection • Connecting to the RJ-45 Connect a standard RJ-45 cable to the network port of the network camera. Generally a cross-over cable is used for directly connection to PC, while a direct cable is used for connection to a hub. -
Page 5: Network Connection And Ip Assignment
Quick Installation Guide 2.2 Network Connection and IP assignment The Network Camera supports the operation through the network. When a camera is first connected to the network it has no IP address. So, it is necessary to allocate an IP address to the device with the “Smart Manager”... -
Page 6: Basic Configuration Of Dome Camera System
2.3 Basic Configuration of Dome Camera System Wire Color Description Red: 12VDC+ Main Power: 2pin terminal White: 12VDC- Pink, Brown Heater Power(Option): 3pin terminal Black: GND Gray: Alarm Input Yellow: GND Alarm Input/Output, RS485: 6pin terminal Black&White: Alarm Output Green: RS485+ Blue: RS485- Black Ethernet: RJ45 Modular Jack... -
Page 7: Setting Dome Camera Address (Id)
2.4 Setting Dome Camera Address (ID) To prevent damage, each dome camera must have a unique address (ID). When installing multiple dome cameras using a multiplexer, it is suggested that the dome camera address match the multiplexer port number. The factory default setting is 1. 2.5 Connections •... - Page 8 2.6 IP Assignment When the dome camera, encoder or decoder is first connected to the network it has no IP address. So, it is necessary to allocate an IP address to the device with the “SmartManager” utility on the CD. 1.
-
Page 9: Getting Started
2.7 Getting Started Once installed apply power to the dome camera. The dome camera will start a configuration sequence. PRESET TITLE AREA TITLE STATUS of AF AE FOCUS and AE FUNCTION UNDER RUNNING CAMERA TITLE INFORMATION EMPTY DATA DISPLAY CAMERA ID DOMEID:001 PAN &... -
Page 10: Chapter 3 - Program And Operation
Chapter 3 — Program and Operation 3.1 Dome Camera Selection Before you program or operate a dome camera, you must select the dome camera by pressing No. + CAM keys. Example: Pressing 1 , 0 + CAM keys sequentially will select dome camera 10. The selected dome camera ID will be displayed on the LCD monitor of the keyboard controller. -
Page 11: Chapter 4 - Operation By Web Browser
Chapter 4 — Operation by Web Browser The network camera can be used with Windows operating system and browsers. The recommended browsers are Internet Explorer, Safari, Firefox, Opera and Google Chrome with Windows. Note: To view streaming video in Microsoft Internet Explorer, set your browser to allow ActiveX controls. -
Page 12: Access From The Internet
4.2 Access from the internet Access from the internet once connected, the network camera is accessible on your local network (LAN). To access the video encoder from the Internet you must configure your broadband router to allow incoming data traffic to the video encoder. To do this, enable the NAT traversal feature, which will attempt to automatically configure the router to allow access to the video encoder. -
Page 13: General Controls
1) General controls The video drop-down list allows you to select a customized or pre- programmed video stream on the live view page. Stream profiles are configured under Setup > Basic Configuration > Video & Image. The resolution drop-down list allows you to select the most suitable one out of video resolutions to be displayed on live view page. -
Page 14: Pan/Tilt/Zoom Controls
Use this scale to control the volume of the speakers. Use this scale to control the volume of the microphone. Use this scale to control the volume of the speakers and microphones. 3) Camera Menu controls If the network camera has been appropriately configured, the Live View page displays the controls available for the OSD menu. -
Page 15: Resetting To The Factory Default Settings
4.6 Resetting to the factory default settings To reset the network camera to the original factory settings, go to the Setup > System > Maintenance web page or use the control button on the network camera, as described below: • Using the Reset Button Follow the instructions below to reset the network camera to the factory default settings using the Reset Button. - Page 16 22X PTZ III NETWORK DOME CAMERA 50302800B Printed in Korea...
