− or (One or All block): Click to select or clear one or all blocks at a time.
−
(Area): Click to select or clear several blocks of an area.
− Trip Direction: Select the direction of the moving to be considered as an event. Selecting In
considers a moving as an event when the moving to the area is detected, and selecting Out
when the moving from the area is detected
 Motion Ignoring Interval: Select the motion ignoring dwell time from the drop-down list. The
camera will not log or send notifications of motion events occurring during the preset interval
after a motion is detected. You can control excessive event logging and remote notifications
of motion detection events by adjusting the motion ignoring dwell intervals.
 Daytime: Set up the daytime range. The camera will consider the remaining time range as the
nighttime.
 Event Action: Check the box for each action the camera is to take when it detects a trip-zone event.
− Alarm Out: Check the box to trigger an alarm-output signal (alarm supported model only).
− Send Email: Check the box to send an email. Selecting Image Attachment attaches an event
detected image file (.JPG) to the email.
− Remote Callback: Check the box and select the remote systems to send a message (Not
supported for the WebGuard program).
− Audio Alarm: Check the box and select the audio file (.wav) to sound (audio supported model
only).
− FTP Upload: Check the box to upload images to an ftp server.
− Move PTZ to: Select the desired preset number to move to. You must set preset locations
using remote programs.
NOTE: You must properly configure the settings related to each event action when setting them
up to enable event actions. Refer to the Event Action setup.
.
