How To Use The Plc Compatibility And Connection Charts; Example - C-more micro EA1-S6ML Hardware User Manual

Chapter 6: PLC Communications

How to use the PLC Compatibility and Connection Charts

1.) Find the PLC Family being used.
2.) Find the particular PLC model in the PLC family.
3.) Find the PLC communications port you will be connecting to the C-more Micro-Graphic
panel.
4.) Read across the chart to determine if the C-more Micro-Graphic panel's Port1 and / or Port2
can be used and then determine the cable and other components, manufactured or user
constructed, are required.

Example:

6
Family
CLICK
all versions
all versions
Direct LOGIC
DL05
6–8
PLC Compatibility & Connection Chart
PLC
PLC Port &
CPU
Type
Port 1
RJ12 - 6 pin
Port 1
RJ12 - 6 pin
Port 2
RJ12 - 6 pin
Port 1
RJ12 - 6 pin
D0-DCM
Port 2
DB15HD
(female)
®
EA1-MG6-USER-M Hardware User Manual, 1st Ed. Rev C, 09/10
C-more Micro-Graphic Panel
Panel to PLC Cabling Components Required for
Specific Port and Protocol being used.
**PLC Port Powered
or
External DC Power Supply
Using panel's RJ12 Port1
Protocol(s) Components &
Supported Network Type
AutomationDirect DV-1000CBL*
Modbus (CLICK) RS-232
K-sequence,
DV-1000CBL*
Direct NET,
RS-232
Modbus RTU
DV-1000CBL*
RS-232
K-sequence,
Direct NET,
DV-1000CBL*
Modbus RTU
+ FA-15HD
RS-232
External DC Power Supply
Using panel's Port2
DB 15-pin - female
Protocol(s) Components &
Supported Network Type
AutomationDirect EA-2CBL
Modbus (CLICK) RS-232
K-sequence,
EA-2CBL
Direct NET,
RS-232
Modbus RTU
EA-2CBL
RS-232
K-sequence,
EA-2CBL-1
Direct NET,
RS-232
Modbus RTU
** See Diagram 1
RS-422
** See Diagram 2
Modbus RTU RS-485
Modbus only
