Chapter 2: Specifications
Model Specifications (cont'd)
Screen Objects:
2
• Functional Devices
• Static Shapes
• Displayable Fonts
Electrical:
• Input Voltage Range
• Input Power
• Power Consumption
• Recommended Fuse
• Max. Inrush Current
• Acceptable External
Power Drop
Environmental:
• Operating Temperature
• Storage Temperature
• Humidity
• Environmental Air
• Vibration
• Shock
• Noise Immunity
• Enclosure
• Agency Approvals
Physical:
• Dimensions
• Enclosure Mounting
Thickness Range
• Mounting Clip Screw
Torque Range
• Depth from bezel rear
• Weight
2–4
Specifications (cont'd)
Push Button, Switch, Indicator Button, Indicator Light, Graphic Indicator Light, Numeric
Display, Numeric Entry, Inc/Dec Value, Bar Graph, Bitmap Button, Static Bitmap, Dynamic
Bitmap, Recipe Button, Static Text, Lookup Text, Dynamic Text, Screen Change Push Button,
Screen Selector, Adjust Contrast, Function, Key Configuration Object, Real Time Graph,
Fixed fonts: 6x6, 6x8, 8x16, 16x16, 32x16, 32x32, and Windows fonts
Low Power Mode
5.0 VDC (4.75 – 5 25 VDC)
Supplied through the panel's RJ12 serial
communications port connection when used
with most AutomationDirect PLCs having a
RJ12 communication port or from a PC during
programming.
1.05 W @ 5 VDC (210 mA)
No fuse required when directly connected to a
PLC or PC with recommended cable.
1 A for 500 µs
IEC60068-2-6 (Test Fc), 5-9 Hz: 3.5 mm amplitude, 9-150 Hz: 1.0G, sweeping, at a rate of
1 octave/min. (±10%), 10 sweep cycles per axis on each of 3 mutually perpendicular axes
IEC60068-2-27 (Test Ea), 15 G peak, 11 ms duration, three shocks in each direction
per axis, on 3 mutually perpendicular axes (total of 18 shocks)
NEMA 4/4X, IP-65 (When mounted correctly, for indoor use only.)
CE (EN61131-2), UL508, CUL Canadian C22.2 No. 142-M95, UL File E157382
6.850" (W) x 5.331" (H) x 2.13" (D) [174.0 mm x 135.4 mm x 54.1 mm] (Landscape Mode)
5.331" (W) x 6.850" (H) x 2.13" (D) [135.4 mm x 174.0 mm x 54.1 mm] (Portrait Mode)
® EA1-MG6-USER-M Hardware User Manual, 1st Ed. Rev C, 09/10
Line Graph, Analog Meter.
Lines, Rectangles, Circles and Frames
12/24 VDC (10.2 – 26.4 VDC)
Supplied from an external 12-24 VDC power
6.5 W @ 10.2 VDC (630 mA),
12 VDC (540 mA), 24 VDC (250 mA)
Type AGC fast acting glass fuse,
750 mA, 250 VAC, ADC p/n AGC-75
Maximum 1 ms
0 to 50 °C (32 to 122 °F)
–20 to +60 °C (–4 to +140 °F)
5–95% RH, non-condensing
No corrosive gases permitted
NEMA ICS3-304
RFI, (145 MHz, 440 Mhz 10 W @ 10 cm)
Impulse 1000 V @ 1 µs pulse
0.04" – 0.2" [1 – 5 mm]
21 – 28 oz-in [0.15 – 0.2 Nm]
1.894" [47.1 mm]
30.69 oz. (870 g)
High Power Mode
source
10 A for 500 µs
