C-more micro EA1-S6ML Hardware User Manual page 117

User Constructed Cables – Wiring Diagrams (cont'd)
Diagram 7
To PLC
9-Pin Port
9-pin
D-sub
(male)
6 = do not use
9
1 = do not use
7 = do not use
2 = TXD
8 = do not use
3 = RXD
9 = Signal GND
4 = RTS
1
5 = CTS
Note: Use the above wiring diagram to make your own cable. We recommend using 22 AWG shielded cable.
Diagram 8
To Peripheral
Port Cable
9-pin
D-sub
(male)
9
1 = do not use
6 = do not use
2 = RXD
7 = do not use
3 = TXD
8 = do not use
4 = do not use
9 = do not use
1
5 = Signal GND
Note: Use the above wiring diagram to make your own cable. We recommend using 22 AWG shielded cable.
®
Omron FINS (CQM1, CPM1, CPM2, C200, CJ1 & CS1)
RS-232C
Wiring Diagram
2
TXD
3
RXD
9
SG
4
RTS
5
CTS
shield
Omron Host Link CQM1 using
CQM1-CIF02 Peripheral Port Connecting Cable
RS-232C
Wiring Diagram
3
TXD
2
RXD
5
GND
shield
EA1-MG6-USER-M Hardware User Manual, 1st Ed. Rev C, 09/10
Chapter 6: PLC Communications
User Constructed
To C-more Micro-Graphic
15-pin
D-sub
8 = do not use
(male)
7 = do not use
3
RXD
6 = do not use
2
TXD 5 = Logic GND
5
4 = do not use
3 = RXD (232C)
2 = TXD (232C)
1
1 = Frame GND
1
User Constructed
To C-more Micro-Graphic
15-pin
D-sub
8 = do not use
(male)
7 = do not use
6 = do not use
3
RXD
5 = Logic GND
2
TXD
4 = do not use
5
3 = RXD (232C)
2 = TXD (232C)
1
1 = Frame GND
1
Serial Port2
15 = do not use
14 = do not use
13 = do not use
15
12 = do not use
11 = do not use
10 = do not use
9 = do not use
6
Serial Port2
15 = do not use
14 = do not use
13 = do not use
15
12 = do not use
11 = do not use
10 = do not use
9 = do not use
6–29
