C-more micro EA1-S6ML Hardware User Manual page 166

Appendix A: Panel & PLC Error Code Tables
GE SNPX Protocol– PLC Error Code Tables (cont' d )
A
Panel Error Code
P499 Hex Value
0x530C
0x530F
0x540C
0x540F
0x550C
0x550F
0x560C
0x600C
0x600F
0x610C
0x610F
0x620C
0x620F
0x630C
0x640C
0x650C
0x660C
0x700C
0x700F
0x710C
0x710F
0x720C
0x720F
0x730C
0x730F
0x740C
0x750C
0x760C
(PLC generated error codes for the GE Fanuc 90-30, 90-70 and VersaMax SNPX protocol
continued on the next page.)
A–18
PLC Errors for GE SNPX Protocol (Minor-Major) (cont'd)
An invalid message type was received when an X-Attach Response was required when re-establishing an
existing SNP-X communication session.
Communications have not been established.
An invalid Message Type was received when an X-Attach message was required. (For an X-Attach message,
the message type must be 58h = 'T'.)
An invalid Next Message Type value was detected in an X-Attach Response message when re-establishing
an existing SNP-X communication session.
Communications have not been established.
An invalid Next Message Type value was detected in a received X-Attach message. (For an X-Attach
message, the Next Message Length must be zero.)
An invalid response code was detected in an X-Attach Response message when re-establishing an existing
SNP-X communication session.
Communications have not been established.
An invalid request code was detected in a received X-Attach message.
An expected X-Attach Response message was not received within the response timeout interval when re-
establishing an existing SNP-X communication session. The master has retried the X-Attach message twice
without receiving a response. Communications have not been established.
A parity error has occurred on an X-Response message.
A parity error has occurred in a received X-Request message.
A framing or overrun error has occurred on an X-Response message.
A framing or overrun error has occurred in a received X-Request message.
A BCC (Block Check Code) error has occurred on an X-Response message.
A BCC (Block Check Code) error has occurred in a received X-Request message.
An invalid message type was received when an X-Response message was required.
An invalid next message type value was detected in an X-Response message.
An invalid response code was detected in an X-Response message.
An expected X-Response message was not received within the response time.
A parity error has occurred on an Intermediate Response message.
A parity error has occurred in a received X-Buffer message.
A framing or overrun error has occurred on an Intermediate Response message.
A framing or overrun error has occurred in a received X-Buffer message.
A BCC (Block Check Code) error has occurred on an Intermediate Response message.
A BCC(Block Check Code) error has occurred in a received X-Buffer message.
An invalid message type was received when an Intermediate Response message was required.
An expected X-Buffer message was not received.
An invalid next message type value was detected in an Intermediate Response message.
An invalid response code was detected in an Intermediate Response message.
An expected Intermediate Response message was not received within the response timeout interval.
® EA1-MG6-USER-M Hardware User Manual, 1st Ed. Rev C, 09/10
Description
