21-Button Portrait (Vertical) Keypad Bezel - C-more micro EA1-S6ML Hardware User Manual

21-Button Portrait (Vertical) Keypad Bezel

The 21-button keypad bezel is designed to be used with the C-more 6" Micro-Graphic panels.
The keypad includes four directional arrow cursor buttons, a full numeric keypad, and one
each of an ESCAPE, MENU, CLEAR and two ENTER buttons. The keypad is intended to
be used with the numeric entry object to allow changing of a value, and can also be used to
navigate & select screen objects. The numeric buttons can be used to enter a new value, or use
the cursor left and right buttons to select a digit and the cursor up and down buttons to
change the value, along with the ENTER and CLEAR buttons. It can also be used to access
and navigate the screen selector feature. The keypad bezel is designed for easy drop-in of a
C-more 6" Micro-Graphic panel. No panel configuration is required.
EA-MG6-BZ2P
Panel Cutout
BEZEL
OUTLINE
0 382
[9 7]
CUTOUT
+0 04
9 236
0 00
+1
234 6
0
R0 59 [R1 5]
0 382
[9 7]
+0 04
5 630
0 382
0 00
+1
[9 7]
143 0
0
21-Button Keypad Bezel continued at top of next page.
® EA1-MG6-USER-M Hardware User Manual, 1st Ed. Rev C, 09/10
Dimensions
CUTOUT
OUTLINE
0 382
[9 7]
Chapter 3: Accessories
6 394
[162 4]
5 588
[141 9]
MOUNTING CLIP (Qty 8)
SCREW TORQUE RANGE
21 28 oz in [0 15 0 2 Nm]
GASKET
Esc Esc 7 8 9
4 5 6
M nu M nu
nter nter
1 2 3
CLR CLR
E t E t r 0
+/- +/-
7 8 9
Esc Esc
4 5 6
M nu M nu
En er En er
1 2 3
CLR CLR
Ent r Ent r +/- +/- 0
Panel Thickness
Units Inches [mm]
MOUNTING CLIP
(8) places
2 094
[53 2]
0 394 1 882
[10 0] [47 8]
10 000
[254 0]
9 195
[233 5]
Four directional
cursor buttons,
numeric buttons,
and ESC, MENU,
CLEAR and two
ENTER buttons.
ENCLOSURE MOUNTING
THICKNESS RANGE
0 04" 0 2" [1 5mm]
3–11
