Panel Dimensions

Panel Dimensions

4.770
[121.3]
Enclosure Thickness
®
2.13
1.453
1.689
[54.1]
[36.9]
[42.9]
.236
[6.0]
Units: Inches [mm]
5.331
[135.4]
ENCLOSURE MOUNTING
THICKNESS RANGE
0.04" - 0.2" [1 - 5mm]
EA1-MG6-USER-M Hardware User Manual, 1st Ed. Rev C, 09/10
Chapter 2: Specifications
6.295
[159.9]
6.850
[174.0]
Mounting Clip Screw Torque
MOUNTING CLIP
SCREW TORQUE RANGE
21 - 28 oz-in [0.15-0.2 Nm]
R 1 1 2 3 4 5
MODE : A - 6MLW
N UT 12 2 V 6 5W
S D
D te od :****
M 7
MADE N CH NA ND.CONT EQ.
EA - 6MLW {0 52 15 01 1
MOUNTING CLIP
(4) places
GASKET
2–5
