USB to RS232 Programming Cable Assembly (cont'd)
Part Number:
Description:
Hardware:
• USB Interface
• Serial Interface
• Baud Rate
• Input Voltage
• Power Consumption
Accessory Cables:
• USB Cable
• Serial Cable
Environmental:
• Operating Temperature
• Storage Temperature
• Humidity
• Environmental air
• Vibration
• Shock
Physical:
• Dimensions
• Weight
* Note: Maximum cable length for either the USB or serial cable should not exceed 2.0 m [6.56 feet] in length.
®
USB to RS232 Converter Specifications
6-ft. cable assembly to connect personal computer to any C-more Micro-Graphic panel for
setup and programming. (Note: This cable assembly uses the PC's USB port and converts the
signals to serial transmissions. The USB port supplies 5 VDC to the C-more Micro-Graphic
panel for low-power mode configuration operations.) Assembly includes standard USB A-
type connector to B-type connector cable, custom converter, and an RS232C cable with RJ12
modular connector on each end.
Connector: USB Type B jack to accept USB Type B cable plug
Connector: RJ12 phone jack 6p to accept RJ12 cable plug
50 mA (Does not include power to panel and/or bezel.)
USB Type A plug to PC on one end, USB Type B plug to converter on other end,
RJ12 phone plug connectors on both ends, 2.0 m [6.56 feet] length (* Note)
IEC60068-2-6 (Test Fc), 5-9 Hz: 3.5 mm amplitude, 9-150 Hz: 1.0G, sweeping, at a rate of
1 octave/min. (±10%), 10 sweep cycles per axis on each of 3 mutually perpendicular axes
IEC60068-2-27 (Test Ea), 15 G peak, 11 ms duration, three shocks in each direction
per axis, on 3 mutually perpendicular axes (total of 18 shocks)
EA1-MG6-USER-M Hardware User Manual, 1st Ed. Rev C, 09/10
EA-MG-PGM-CBL
USB Specification Rev. 1.1
RS232 (EIA-232-E)
115.2 kbps Maximum
5 VDC (Supplied thru serial interface cable.)
0.30 m [1 foot] length (* Note)
0 to 50 °C (32 to 122 °F)
-20 to 60 °C (-4 to 140 °F)
5 to 95 % RH (non-condensing)
No corrosive gases permitted
2.559" (W) x 1.417" (H) x 0.886" (D)
[65.0 mm x 36.0 mm x 22.5 mm]
1.06 oz. [30 g]
