Setting – Backlight, Model EA1-S6MLW
SETTING
1 LCD Contrast
2 Backlight
3 Beep
4 Ca ibration
5 Clear User Memory
6 Reset to Factory Default
BACKLIGHT
Current Value
Pink1
BACKLIGHT
Current Value
Pink3
Note: Loading a project to the panel will override whatever color is choosen from the System Setup Screens'
Backlight color selection screen. The selected color is displayed only when in the System Setup Screens.
®
With Backlight
highlighted, press
BAK
ENT [F5] to show
the current
NXT
>
>
backlight screen
>
UP
>
color. For model
DWN
EA1-S6MLW, the
ENT
ENT default is white. The
UP [F3] and DWN
[F4] function keys
can be used to scroll
through the five
available backlight
colors (white, pink1,
BAK
pink2, pink3 and
red). Use the APL
pink1
[F5] function key to
UP
apply the new color.
DWN
Shown here are the
ENT
APL
various backlight
colors.
BAK
pink3
UP
DWN
ENT
APL
