Appendix A: Panel & PLC Error Code Tables
GE SNPX Protocol– PLC Error Code Tables (cont' d )
A
Panel Error Code
P499 Hex Value
0x080C
0x080E
0x080F
0x090C
0x090E
0x0A0C
0x0A0E
0x0B0C
0x0B0E
0x0C0C
0x0D0C
0x0E0C
0x0F0C
0x100C
0x100F
0x110C
0x120C
0x130C
0x140C
0x150C
0x150F
0x160C
0x170C
0x180C
0x190C
(PLC generated error codes for the GE 90-30, 90-70 and VersaMax SNPX protocol
continued on the next page.)
A–14
PLC Errors for GE SNPX Protocol (Minor-Major) (cont'd)
Unable to read or write master device memory locations specified in COMMREQ. Usually caused by invalid
memory address for this PLC. SNP message exchange may have taken place.
Modem responded with NO DIALTONE. Modem is unable to complete the requested connection. Check the
modem connections and the telephone line.
Service Request Processor response exceeds 1000 bytes;
the SNP-X slave device cannot return the data in an X-Response message.
(This error applies to CMM module only.)
Master device memory data length exceeds maximum data size of CMM module (2048 bytes). Must use a
smaller data length. Use multiple COMMREQs if total data length exceeds this maximum value.
Modem responded with ERROR. Modem is unable to complete the requested command. Check the modem
command string and modem.
Slave device memory type is missing or not valid.
Modem responded with RING, indicating that the modem is being called by another modem. Modem is
unable to complete the requested command. Retry the modem command at a later time.
Slave device memory address is missing or zero.
An unknown response was received from the modem. Modem is unable to complete the requested
command. Check the modem command string and modem. The modem response is expected to be either
CONNECT or OK.
COMMREQ Data Block Length is too small.
(When expected COMMREQ length is 6 words or less. An improper length may cause other minor error
codes 6-11.)
Invalid Diagnostic Status Word (DSW) starting word or length.
Invalid maximum SNP message data size.
Must be an even value from 42 to 2048.
Invalid Privilege Level. Must be 0 through 4 or -1.
Invalid Fault Table selector.
Must be 1 for I/O Fault Table, or 2 for PLC Fault Table.
Unexpected Service Request Processor error.
(This error applies to CMM module only; the unexpected SRP error code is saved in the Diagnostic Status
Words in the CMM module.)
Invalid Fault Table starting index.
Must be 1-32 for I/O Fault Table, or 1-16 for PLC.
Invalid fault count. Must be 1-32 for I/O Fault Table, or 1-16 for PLC Fault Table.
Invalid Set PLC Date/Time mode. Must be 1-4.
Invalid Set PLC Date/Time date, time, or day-of-week value.
Unable to retrieve master device PLC time/date from PLC CPU.
Requested service is not permitted in a Broadcast request. The master must direct the X-Request message
to a specific SNP-X slave device.
Invalid slave PLC type.
Must be 0 for Series 90-70, or 1 for Series 90-30 or Series 90-20.
Invalid datagram type.
Must be 01h for normal datagram, or 81h (129) for permanent datagram.
Missing or too many datagram point formats. Must be 1-32.
Invalid datagram point format data.
® EA1-MG6-USER-M Hardware User Manual, 1st Ed. Rev C, 09/10
Description
