Chapter 6: PLC Communications

C-more 6" Micro-Graphic Communication Ports

Example of panel's Port1
connected to a CLICK PLC
CLICK PLC
6
Example of panel's Port2
connected to a DL06 PLC
C-more 6 Inch
Micro-Graphic
6–4
C-more 6 Inch
Micro-Graphic
Panel
Port 2
Port
2
Panel
®
EA1-MG6-USER-M Hardware User Manual, 1st Ed. Rev C, 09/10
Port 1
DV-1000CBL
serial cable
DL06 PLC
Direct LOGIC
VGA 15-pin port
serial cable
p/n EA-2CBL-1
Port
2
Panel to
