5.38 Screen Saver

The handset screen saver can be configured to display information or turn off the backlight
so that no information is shown. To configure the screen saver:
1 In the PDM/Device Manager, select Device > Settings.
2 In the Screen saver drop-down list, select one of the following:
• Information: Dims the backlight but keeps sufficient light to display time and
status information, such as message indications.
• Black: The screen goes black and the backlight is turned off.
• Black also in call: The screen goes black and the backlight is turned off, as for the
"Black" option. In addition, the backlight is turned off when the handset is in call.
This helps extend battery life especially when the user is on an extended call.

5.39 Profiles

5.39.1 User Profiles

An own profile can be setup for incoming calls, message alerts, message volume, vibrating
alerts, key sound etc. This can be useful when there are many users on the same handset
who want different sound profiles. It can also be used for temporarily settings, for example
while in a meeting, incoming calls should be silent.
1 Select User Profiles > User Profile X (where X represents 1 - 4).
2 In the Name text field, enter the name of the profile.
The name is visible in the handset and becomes a selectable option in User Profiles >
Active Profile.
3 Select the settings to be edited. For example Sound and alerts, Soft keys etc.
4 If required, select the profile to be activated in the handset by selecting User Profiles
> Active Profile.
Tip: Profiles can also be configured via the handset menu. See User Manual, Ascom d62
DECT Handset, TD 92477GB.

5.39.2 System Profiles

Note: This feature is applicable for d62 Messenger and d62 Protector only.
A system profile can be setup to force a handset to use certain settings that the user is
unable to modify. The system profile is set up in two steps:
1 Create sub groups.
2 Create system profile using the predefined sub groups.
Configure Presence settings group (sub group)
1 Select System Profiles > System Profiles Sub Groups > Presence groups > Presence
group X
2 In the Message absence drop-down list, select one of the following:
• On - When a handset receives a message, it indicates that it is absent. The
message can be redirected to another destination and is system dependent.
• Off - The message absence is disabled.
3 In the Name of group field, enter a descriptive name.
