5.34.1 Selection of Corded Headset Type

To achieve optimal audio quality with the different headset types, it is recommended to set
the corresponding headset type. The default setting is "microphone on a boom", which
means that the audio is optimized for using a headset with microphone on a boom. The
headset type can be changed as follows:
1 Select Connections > Headset.
2 In the Headset type drop-down list, select the corresponding headset type to be
used.
If "User headset profile" is selected, see the section
User headset profile
If the preconfigured headset profiles does not match the headset or the audio performance
is unsatisfactory, a headset profile can be configured in the following way:
1 Select Connections > Headset > User headset profile.
2 In the Name of user headset profile field, enter an appropriate name. The name is
visible and selectable in the handset menu.
3 In the Headset mic adjustment drop-down list, select the microphone gain to be used.
4 In the Headset speaker adjustment drop-down list, select the speaker gain to be
used.
Note: Changing these parameters may result in a very high sound level which can cause
hearing damage. In addition, these parameters may result in lower sound quality such as
noise and echo. If the audio problems occur, it is noticable for the person listening on the
conversation. Evaluate carefully before applying.

5.34.2 Configuration of Headset Button

Note: This feature is not applicable for d62 Talker.
The headset answer button can be configured with a predefined function.
Configure a corded headset button
1 Select Connections > Headset.
2 In Headset type drop-down list, select headset to be used.
3 In the Call with headset button drop-down list, select one of the following:
• Not activated - a call can only be answered or ended.
• Last called number - the last called number is dialled.
• Predefined number - a predefined number is called (if selected, continue with step
3)
• Hook off - activates the post-dial function, that is, a dial tone is heard and the
user can enter the number to be called.
4 If required, enter the number to be dialled when the headset button is pressed in the
Predefined number field.
Configure a Bluetooth headset button
Note: See the User Manual for the Bluetooth headset for more information on how to
connect it and use its answer button. This feature is not applicable for d62 Talker.
