Configuration Manual
Ascom d62 DECT Handset
1
Select "System profiles".
2
In the Active system profile on phone drop-down list, select one of the following:
• Normal - no system profile is used.
• [System profile]
System Profile Activation and Deactivation Audible Alert
The administrator may configure the handset to play a sound if the system profile is
activated or deactivated. This provides the user with an audible alert when the system
profile changes from inactive to active or vice versa. The feature can be triggered by several
kinds of event, such as moving between different parts of a buildings where a system profile
might be appropriate in one location but not required in another.
To configure the handset to play a sound when a system profile is activated or deactivated,
perform the following steps:
1
Select "System profiles".
2
From the "System Profile X" list select the system profile where the audible alert is to
be applied.
3
Set the "Activation and deactivation sound" parameter to the required customized
sound.

5.40 Shortcuts

One click access to predefined functions can be configured for the Soft keys, Hot keys,
Navigation keys, and the Multifunction button. For example a soft key can be configured to
make a call.
Shortcuts are configured via parameters in the "Shortcuts" folder.
Note: When programming Soft keys both name and function must be set.
Note: A hot key configured to the Data Send service is also available during the call.
Tip: Shortcuts can also be configured via the handset menu. See User Manual, Ascom d62
DECT Handset, TD 92477GB.

5.40.1 Restricting Access to Shortcuts

For some application areas, it may be a requirement that the user is prevented from defining
shortcuts to predefined functions via the handset Shortcuts menu. Setting a shortcut to
"Read only" via the PDM/Device Manager enforces this restriction. To access the parameters
associated with shortcuts, perform the following steps:
1
Select Shortcuts.
2
Select the required shortcut parameter:
Hot keys 0, 2 through 9 and "Hook Off"
Soft Keys "Left", "Middle" and "Right"
Navigation keys "Up", "Down", "Left", "Right" and "OK"
31 October 2013 / Ver. J
TD 92639EN
52
