Configuration Manual
Ascom d62 DECT Handset
1 In the Call with headset button drop-down list, select one of the following:
• Not activated - a call can only be answered or ended.
• Last called number - the last called number is dialled.
• Predefined number - a predefined number is called (if selected, continue with step
3)
• Hook off - activates the post-dial function, that is, a dial tone is heard and the
user can enter the number to be called.
2 If needed, in the Predefined number field, enter the number to be dialled when the
headset button is pressed.

5.35 Display New Messages and Call Information Upside Down

New messages and call information can be displayed upside down. This can be useful if the
handset is worn in a belt and messages or call information need to be read without rotating
the handset. When pressing any key, the messages are displayed in the normal way.
1 Select Settings > Display
2 In the Rotate display text drop-down list, select one of the following:
• On - New messages and call information are rotated 180 degrees.
• Off - Disables the rotation function.

5.36 Display Management Layout

In the Active area of the display, the first 2 rows can show 12 characters each by default.
The number of rows and characters to be displayed in idle mode or during a call up can be
extended to 3 rows with 16 characters each. When extending the rows or characters, the
System name or Owner ID is hidden to provide space for system dependent information
instead.
NOTE: All settings except the default setting require an IP-DECT system with software
version 5.0.x or higher.
1 Select System X.
2 In the Display Management Layout drop-down list, select one of the following:
• 2x12 characters
• 2x16 characters
• 3x16 characters, remove Owner ID
• 3x16 characters, remove system name

5.37 Owner Identification in the Idle Display

Owner identification can be added while the handset is in standby mode. In a template or
Number in PDM/Device Manager, the parameter is found at:
Settings > Owner ID
Note: The Owner ID might not be displayed depending on the setting in
Management
Tip: The Owner ID can also be configured via the handset menu. See User Manual, Ascom
d62 DECT Handset, TD 92477GB.
31 October 2013 / Ver. J
Layout.
TD 92639EN
