Configuration Manual
Ascom d62 DECT Handset
4 If the PBX is configured only for CLIP and no name resolution was possible because
the local phonebook had no entry corresponding to the calling party number, only the
calling party extension number can be displayed in the handset.
5.29.2

Display Management Parameter

If information about a caller exists in the local phonebook, a display management parameter
can be configured to show this information in addition to the information provided by the
display manager. The additional information is displayed as additional lines of text in the
handset display. The parameter is accessed through the PDM/Device Manager by selecting:
Systems > System X > Display Management and Local Phonebook Name
The parameter can be set to one of the following values:
• Normal: The handset shows only the display management text.
• Add name internal and external call: Additional detail about the caller is displayed if
there is information about the caller in the local phonebook. If there is no entry for the
caller in the phonebook, only the display management text is displayed. This option
applies when both internal and external calls are received.
• Add name external call: Displays additional caller detail as described above, but only
when external calls are received.

5.30 Services

Note: This feature is applicable for d62 Messenger and d62 Protector only.
From PDM/Device Manager, up to 10 services can be configured that can be accessed from
the Services menu. Soft keys can also be configured to access services quickly. A list of
predefined functions are available such as Phone call, Send message and Send data.

5.30.1 Add Service

1 Select "Services".
2 Select the service (1 - 10) to be configured.
3 In the Name field, enter the name of the service. The service name is displayed in the
handset.
4 In the Type drop-down list, select the function (Send Message, Phone Call or Send
data) to be used.
5 If needed, in the Number field, enter the destination number for the message/call/
data. The following values can be entered in the Number field: Digits 0-9, #, *, P –
pause, H – hook.
Tip: If the Phone call function was selected, an additional character U can be entered
in the Number field. The handset prompts the user to enter numerical characters
before establishing a call (procedure call).
6 If needed, in the Prefix field, enter the prefix to be used.

5.30.2 Delete Service

1 Select "Services".
2 Select the service (1 - 10) to be deleted.
3 In the Name field, delete the name of the service.
31 October 2013 / Ver. J
TD 92639EN
45
