Configuration Manual
Ascom d62 DECT Handset

5.10 Own Line Settings

Use own line settings if the same phonebook is to be used in different systems and in
different countries.
The own line settings enables:
• Calling numbers stored with a "+" sign for the international access code. The same local
phonebook can be used in different countries.
• The recognition of incoming internal or external calls as numbers stored in international
format in the local phonebook. The same phonebook can be used in different systems.
For this feature to work, numbers must be stored in the local phonebook in international
format with a "+" sign for the international access code. Also, the Own Line parameters must
be configured via the PDM/Device Manager.
For instructions on how to work with PDM/Device Manager, see Installation and Operation
Manual, Portable Device Manager (PDM), Windows Version, TD 92325EN, or Installation and
Operation Manual, IMS3, TD 92762EN.

5.11 Configure DTMF

Some legacy systems and PBXs require that the handset sends DTMF tones when pressing
or releasing the PTT button or when pressing the On-hook key to end a call.
NOTE: This is only applicable for d62 Messenger and d62 Protector.

5.11.1 Send DTMF Tone when Pressing On-Hook key

1 Select Settings > DTMF.
2 In the On-hook DTMF tone drop-down list, select the DTMF tone to be sent when the
On-hook key is pressed.
To disable the DTMF tone, select "Not used".

5.11.2 Send DTMF Tones when Pressing or Releasing the PTT Button

1 Select Settings > DTMF.
2 In the Push to talk DTMF tones drop-down list, select "On".
3 In the PTT DTMF ton on push drop-down list, select the DTMF tone to be sent when
pressing the PTT button.
4 In the PTT DTMF ton on release drop-down list, select the DTMF tone to be sent when
releasing the PTT button.
To disable the DTMF tones, select "Off" in the Push to talk DTMF tones drop-down list.

5.12 Uploadable Language

The handset can be loaded with one additional language. The language file is generated via
an Excel file. Excel language files are available from the handset supplier.
Note: If another language file is uploaded, the first additional language is overwritten.
Certain special characters are allowed when generating the language file, see information in
the Excel file.
To upload an additional language, the PDM or Device Manager is used, go to the devices tab
and select devices. In the Device menu, select "Upload language...".
31 October 2013 / Ver. J
TD 92639EN
26
