In Charger Action When In Call; Clear Lists When Inserted In Charger - ASCOM d62 Talker Configuration Manual

Configuration Manual
Ascom d62 DECT Handset
Show and indicate incoming messages parameter.
• Logout - the handset is logged off when placed in charger. This option is only
visible if the license dependent Shared Phone feature is enabled.
• Message absence - if a message is sent from a system, it is notified that the
handset is absence.
• Change profile - the handset changes profile when placed in charger.
In the Change to profile drop-down list, select the profile to be used. By default,
only the profile Normal is selectable. If configured, additional profiles are visible,
see
• Show and indicate incoming messages while charging
Determines how incoming messages are displayed or indicated when the handset
is placed in charger. If this parameter is set to No, the message alert, if any, is
muted and only the New message icon is displayed. The messages are stored as
unread messages in the Messaging Inbox.

NOTE: All incoming messages are affected by this setting; that is PTT invitation
received as message, and all other messages regardless of priority (even
messages with breakthrough such as high/alarm priority). To only silence
messages without breakthrough (low/normal priority), set the Sound off
parameter instead.

5.15.2 In Charger Action when in Call

The handset can be configured to end a call, or turn on the loudspeaker when it is placed in a
charger during a call. If the handset is removed from the charger during the call, it does not
revert to the previous settings.
1 Select Connections > In Charger
2 In the Call behaviour drop-down list, select one of the following:
• No action - no action is performed when handset is placed in charger
• End - the handset disconnects calls when placed in charger
Note: Some systems/PBXs require that the handset sends a DTMF tone to end a
call, See
configuration.
• Put on Loudspeaker - the handset activates the loudspeaker mode when placed in
charger.

5.15.3 Clear Lists when Inserted in Charger

The handset can be configured to clear lists when placed in a charger. The following
message and call lists are then cleared:
• Inbox
• Unsent
• Sent
• Call list
• Missed calls
Using the PDM "Edit template" feature, the parameter is found at
Connections > In_Charger > Clear_Lists_In_Charger
in a template or parameter definition file (.def).
1.Applicable for d62 Messenger and d62 Protector only.
31 October 2013 / Ver. J
5.39.1 User Profiles on page 49.
5.11.1 Send DTMF Tone when Pressing On-Hook key
TD 92639EN

1
on page 26 for
30
