5 Select "DECT Location info". DECT information is displayed in the handset display as
shown in
Figure 4. DECT Location Information
For additional information about DECT location, see the Planning Guide, DECT Location, TD
93009.
DECT Location Indications
When the DECT Location info screen is present, the handset can be configured to provide
additional indications to the support engineer as the handset is carried into a valid location.
A beep indication, a LED indication, or both can be activated to indicate when valid locations
are received. The activation parameters that can be configured via the PDM/Device Manager
are as follows:
Location > Indicate location with beep
• Off - The beep indication is turned off
• Beep on new - The handset beeps when it receives a new valid location. A location is
considered as "new" when the location ID is changed for the current location.
• Beep always - The handset beeps when it is receives a valid location.
Location > Indicate location with LED
• Off - The LED indication is turned off
• Blink on new - The LED flashes when the handset receives a new valid location. A location
is considered as "new" when the location ID is changed for the current location.
• Blink always - The LED flashes when the handset receives a valid location.
• Steady always - The LED lights continuously as long as the handset receives valid
locations with a rate not exceeding 1 second.
Location Information during Call
When the Admin menu is activated and DECT location is enabled, the DECT location
information screen can be accessed during a call by pressing the soft key "More" and select
"Location info".
For additional information about DECT location concepts, see Planning Guide, DECT Location,
TD 93009.

5.21 Special Location

A special location is a valid location received by the handset from a location device that is
automatically sent to the system. To prevent the system from being overloaded, a special
location that has already been received in the last three seconds will not be sent to the
31 October 2013 / Ver. J
figure 4:.
Figure 4.
12:34
DECT Location info
LR: 87D6, LV: 002A
SS: -50, T: -60
L1: 0555, t1: 02118 s
L2: 0666, t2: 02115 s
L3: 0444, t3: 02168 s
L4: 0333, t4: 02103 s
Back
